• Model NO.：KU-1000L
• Loading Method：Static Load
• Display：Digital
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC380V
• Oil Cylinder Position：Under
• Capacity(Kw)：18
• Chamber Volume(L)：1000
• Inner Size (D*W*H))：1000*1000*1000mm
• Temperature Range：-70oc~+150oc
• Humidity Constancy：+,-0.5%
• Cooling Rate：0.7oc~1.0oc,Min
• Pressure Range：Normal Pressure~1kp
• Pressurized Parts：High Quality Steel Plate(Rust Proof&Plastic Spray
• Insulation Material：High Quality Glass Wool
• Pump：Rotary Vane Type Vacuum Pump
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：100-500kg

Specifications ModelKU-504LKU-1000LKU-504SKU-1000SInner Size (D*W*H)mm800*700*9001000*1000*1000800*700*9001000*1000*1000Capacity ( KW )11151618Chamber Volume ( L )50410005041000PerformanceTemp range-40 ºC~ +150 ºC-70 ºC~ +150 ºCTemp constancy±0.5 %Temp deviation≥ 100 ºC, ±3.0 ºC( at constant pressure with empty load )< 100 ºC, ±2.0 ºC( at constant pressure with empty load )Cooling rate0.7 ºC~ 1.0 ºC /min ( Overall average )Pressure rangeConstant pressure  ~ 1kPaPressure constancyWhen  ≥ 40kPa, ±2kPa,     4kPa ~ 40pKa  ±0.5kPa,   when ≤ 4kPa, ±0.1kPaDepressurization rateConstant pressure ~ 1kPa≤30mins ( Normal temp )Pressure recovery rate10kPa/Min(adjustable )MaterialExterior materialCold-rolled steel sheet(Rust proof&Plastic Spray treated)/Stainless Steel plateInterior materialStainless steel ( SUS304 )Pressurized partsHigh quality steel plate(Rust proof & Plastic spray treated)  Insulation materialHigh quality glass woolCooling SystemCompressorSemi-Hermetic CompressorCooling ModeWater cooledTemp regulating methodBalanced Temperature & Humidity Control System  (BTHC )PumpRotary vane type vacuum pumpHeaterIron-chrome wire heaterSight windowCircular viewing glass incorporating heat generatorTemp SensorPt-100ControllerTouch Screen Controller  Safety DevicesOver pressure, over heat and over current protection for compressor,
over temp. protection, over load protection for blower,   Hydraulic and Water lack Protection, leakage protection, phase-lack protection, Pump failure alarmStandard AccessorySight window, Cable Port( 1 located on the left side), Baffle, Baffle frame*2  PowerAC380V/50Hz, 3Phase 5 wires+ Ground Wire. Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
