Hipot Tester Power Supply Equipment DC High Voltage Generator
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Power：AC220V+10%, 50Hz+1%
- Output Voltage Indicator Accuracy：<1%
- Output Current Indicator Accuracy：<1%
- Ripple Contain Factor：<0.5%
- 0.75 Times Output Voltage Indicator Accu：<1%, Can Be Locked
- Warranty：12 Months
Base Info
- Model NO.：ZGF
- Output Voltage：400kv
- Input Voltage：220V
- Output Current：4mA
- Output Power：120W~900W
- Transport Package：Wooden Case
- Specification：As different size
- Trademark：Gold
- Origin：Chongqing
- HS Code：9031809090
- Production Capacity：200PCS,Month
Description
Less than 0.5% Features: High reliability: high frequency voltage multi-doubler rectifier, simple circuit, high overload capability, rare fault, without maintenance. Small volume: one person can carry the largest DC HV generator (200kV/2mA). Its volume is only 1/(2~5) as the volume of the same kind of equipment made in Japan. It reaches the advanced level in the world. Perfect seal by metal housing, high mechanical strength. Its performance will not be influenced by vibration, moisture, dust and meteorological condition. Safe, convenience in operation, metal housing grounded. built-in HV terminals. There is no high voltage and low voltage connect outside, easy connection. Good auto protection function. It can nor be switched on if the HV output knob is not at zero position. Operation is simply. It automatically switch off in over voltage and over current case. There is dam pong resistor inside.It is not necessary to connect damping resistor outside. Excellent accuracy: The leakage current at HV side is measured by digital meter accuracy: 1uA, range switch is not required, discharge withstand current measurement function is available at low voltage side, It use precise resistor with good stability to measure high voltage.
