• Model NO.：WE-1000B
• Control：Manual Control
• Weight：1000-2000Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Testing Specimen：for Metal, Wire, Concrete, Brick, Cement
• Loading：Manual Hydraulic
• Certificate：ISO9001:2000
• Precision：1 Grade
• Product Name：Digital Display Hydraulic Material Testing Machine
• Max.Testing Power：1000kn
• Max.Tension Distance：630mm
• Compress Distance：0-490mm
• Clamp thickness of Flat Specimen：0-40mm
• Clamp Width of Flat Specimen：80mm
• Transport Package：Export Standard Wooden Packing
• Specification：1800x1600x2400mm
• Trademark：Yufeng
• Origin：China
• HS Code：9031809090
• Production Capacity：5000pieces,Year

Basic Info.

Model NO. WE-1000B Control Manual Control Weight 1000-2000Kg Power Source AC220V Oil Cylinder Position Under Testing Specimen for Metal, Wire, Concrete, Brick, Cement Loading Manual Hydraulic Certificate ISO9001:2000 Precision 1 Grade Product Name Digital Display Hydraulic Material Testing Machine Max.Testing Power 1000kn Max.Tension Distance 630mm Compress Distance 0-490mm Clamp thickness of Flat Specimen 0-40mm Clamp Width of Flat Specimen 80mm Transport Package Export Standard Wooden Packing Specification 1800x1600x2400mm Trademark Yufeng Origin China HS Code 9031809090 Production Capacity 5000pieces/Year

Product Description

WE-1000B  Analogue Display Hydraulic material testing machine
 Use:
    The machine has the oil cylinder of underneath type and of hydraulic loading control, pendulum test, and three-dimensional gamut. It has the advantage such as high precision and easy to operate. It is suitable for doing testing experiments such as the tensile, compression, bending and shear testing for all kinds of metal materials and nonmetal materials such as plastic, concrete, cement and so on.Accessories:
    Main frame; Control console; Analogue gauge; Sample jaw three sets; Bend support saddle; Bend pressure energy; Spheric compression plate; Lower compression plate; Top board; Ground screw and nut;Inner hexagon spanner; wire power cord; O type gasket; Cruciform screw driver; Double offset ring spanner; Other accessories full sets.
