• Model NO.：GDSL-BX-200
• Display：Digital
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC220V
• Power Supply：AC 220V 50Hz.
• Output Power：3kVA
• Output Current：500A in Series, 1000A in Parallel
• Output Voltage：6V in Series, 3V in Parallel
• Accurancy：1%
• Secondary Injection Current：50A
• Test Range：0.001s-999.999s
• Duty Cycle：5mins on, 10mins off
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：China
• HS Code：9030339000
• Production Capacity：2000PCS,Year

Current can be adjusted smoothly and continuously. The accuracy is 1.0%.Output current is standard sine wave, waveform distortion is less than 5%.Secondary injection current50AOutput currentRMS continuous adjustable.The action time of test object can be tested, the lock action time is also can be recorded at the same time.Test range0.001S-999.999S, resolution 1ms, error: 0.005%, range: ±2digitsDuty Cycle5mins ON, 10mins OFF.
