• Model NO.：HYV-1000
• Trademark：HUANYI
• Origin：China
• HS Code：9031809090
• Production Capacity：100,Year

Basic Info.

Model NO. HYV-1000 Trademark HUANYI Origin China HS Code 9031809090 Production Capacity 100/Year

Product Description

Product introduction

This machine is used for measuring formaldehyde emission from furniture, wood-based panels, composite wood flooring, carpets, adhesives and other materials by climatic chamber method, or for treating wood-based panels with constant temperature and humidity balance. It can also be used for detecting volatile harmful gases in other materials.
Meet the standard
GB18580-2017{Formaldehyde emission from indoor decorative materials, wood-based panels and their products}
IS012460-1-2007{Wood based panels, determination of formaldehyde emission, part I}
LY/T1980-201 1{Volatile organic compounds and Formaldehyde emission testing chamber}
GB1 7657-2013{Test method for physical and chemical properties of wood-based panels and decorative wood-based panels}
ENV717-1{Measurement of formaldehyde emission from wood-based panels}
ASTM D6007-02{Standard Test Method for determination of formaldehyde concentration in wood products by micro scale environmental chamber}
LY/T 16 12-2004{1m3 climate chamber for formaldehyde emission detection}
Characteristic
The inner wall of the chamber is welded with stainless steel, and each corner is arc treated. Formaldehyde is not adsorbed and released. The imported aldehyde-free sealing strip is used for the sealing ring, which can ensure the isolation of the test box from the external environment and minimize the background value as far as possible.

Parameter description

The volume of the climate chamber (m³)	1m³
Internal size (approx.)mm	W850*D990*H1210  (or customized according to customer requirements)
The temperature range	15ºC~40ºC
The temperature fluctuation	<±0.3ºC
Humidity adjustable range	30%~80%
Humidity fluctuation	±2%RH
The temperature deviation	<0.8ºC
The humidity deviation	<±2%
Formaldehyde background concentration	≤0.006mg/m³
Air replacement rate	(0.5-1.5)times/h(accuracy0.05times/h)
The air velocity	0. lm/s~0. 3m/s
The relative positive pressure maintained	10±5pa
Internal material	SUS304 mirror stainless steel Chamfered smooth angle
External material	baking paint
Insulation layer thickness	100mm
Power	AC 220V/50HZ
Starting power	≤5KW
The running power	≤2.8KW
humidified water	Distilled water
Ambient temperature	15ºC~35ºC
Ambient humidity	≤90%RH
