• Model NO.：HTPV -01
• Impact Bag Mass：45± 0.1kg
• Impact Bag Maximum Diameter：250mm
• Delivery：25 Work Days
• Package：Stronger Wooden Case
• Transport Package：Wooden Case
• Specification：IEC 61730: 2-2004 No. 10.10
• Trademark：HOTOTECH
• Origin：Dongguan
• HS Code：9013809000
• Production Capacity：50 Sets Per Month

Basic Info.

Model NO. HTPV -01 Impact Bag Mass 45± 0.1kg Impact Bag Maximum Diameter 250mm Delivery 25 Work Days Package Stronger Wooden Case Transport Package Wooden Case Specification IEC 61730: 2-2004 No. 10.10 Trademark HOTOTECH Origin Dongguan HS Code 9013809000 Production Capacity 50 Sets Per Month

Product Description

Glass Grapeshot Impact Testing machine
Purpose
This machine specialized for testing impact resistance of toughened glass, measuring the penetration resistance Or intensity of toughened glass under different impact height with the same mass


Implementation of standards
1. According to c "Module Rupture Test"
2. According to JJG 128-1999 " Safety Glass Shot Bag Impact Tester"
3. GB9962-1999, suitable for testing impact resistance of laminated glass
4. GB17841-1999, suitable for testing toughened glass and Semi-tempered glass Grapeshot Mas of shot bag should be: 45± 0.1kg Maximum diameter: 250mm
5. Test framework Internal dimensions of sample frame: Length 19200+10mm, width 8450+10mm There should be marked with thickness with 3mm, width with 15mm, hardness A50 ° In the test framework

Company Introduction
  Dongguan Hong Tu Instrument Co.,Ltd specilizes in developing and producing testing machines and our company established in 2006 year , we have firm connection and full cooperation from China's National Third-Party Quality Inspection and Notarization Center on producing and developing testing machines
  We treasure the value of good quality , reasonable price and efficient service with customer satisfaction. we expert ourselves in providing our cusotmers the best suitable testing designs and high quality testing machines to make you utmost profit
