High Voltage Test Equipment/Resonant Withstand Test Equipment

Wuhan Goldhome Hipot Electrical Co., Ltd.
  • Type：Universal Testing Machine
  • Accuracy Grade：1.5
  • Display：Digital
  • Control：Computer Control
  • Weight：0-100Kg
  • Power Source：220V,380V

Base Info

  • Model NO.：HMCXZ
  • Model No.：Hmcxz
  • Product Name：AC Resonant Test System
  • Output Frequency：30 -300Hz
  • Resonant Voltage Waveform：Sine Wave, Thd ≤ 1%
  • Full Load Working Time：Continuous Working Time 60mins
  • Warranty：1 Year
  • Standard：ISO
  • Transport Package：Wooden Box with Foam Inside
  • Trademark：HMDQ
  • Origin：Hubei, China(Mainland)
  • HS Code：9031809090
  • Production Capacity：100sets,Year

Description

Configuration

DUTReactor
27kVA/27kV  4unitsTransformer output35kV/240mm2 Cable(Test voltage:52KV)Length 1000m  2 Reactors in parallel and 2 Reactors in series3kV10kV/300mm2 calbe
(Test voltage:24KV)Length 2000m4 Reactors in parallel1.5kV10.5KV/20KV Generator(Test voltage:24KV)60/130KW4 Reactors in parallel1.5kV10kV/35KV Power transformer (Test voltage:44/95KV)
 GIS,Tranformer,
Insulators.. 2 Reactors or 4 Reactors in series5KV
Sr no Description   SpecificationQty
1Variable frequency power supply
CHXB-6KV/380V/220V		- Rated output capacity: 6KW
- Power Supply: 220V/380V ± 15% (single phase), 50Hz
- Output Voltage: 0 - 400V, adjustable;
- Rated Output Current: 0-15A;
- Frequency: 30 - 300Hz, 0.1Hz step adjustable
- Frequency resolution:  0.1Hz
- Frequency stability: ≤ 0.02%		1 unit
2Excitation Transformer
JLB-6KVA/1.5KV/5KV/0.2KV/0.4KV
 		- Rated capacity: 6KVA;
- Input voltage: 400V/200V, single phase;
- Output voltage :1.5kv/3KV/5kV;
- Output current :4A/2A/1.2A;
- Frequency:30-300Hz;		1 unit
3Reactor
DK-27KVA/27KV		- Rated Capacity: 27kVA;
- Rated voltage: 27kV;
- Rated current: 1A;
- Induction:110H/each one
- Continous wroking time: 60mins;
- Temperature rising: <60ºC
- Working frequency: :30-300Hz.		4 units
4Capacitive Divider
FRC-120KV/1000PF		- Rated voltage: 120KV
- High-voltage capacitance: 1000pF
- Frequency:30-300Hz		1 unit
