• Model NO.：GD-0518
• Origin：Made in China
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-0518 Origin Made in China HS Code 9031809090 Production Capacity 100sets/Month

Product Description

-40C Low Temperature Kinematic Viscometer Bath ASTM D445



Introduction:

The Low Temperature Kinematic Viscometer Bath is suitable for determining the low temperature viscosity of petroleum products. The mechanism of the instrument is to measure the time during which a certain volume of liquid flows under gravity through a calibrated glass capillary viscometer at a constant temperature. The product of the capillary constant of the viscometer and the flow time is the kinematic viscosity of the liquid measured at that temperature.


Main Features:

1. Dewar flask as a bath, transparent observation.
2. One-piece structure, easy to operate.
3. Vacuum Dewar insulation, inner cylinder 150×300mm.
4. Two samples can be tested at the same time, which is convenient for parallel samples.
5. High-power solid-state relay control output, no voltage leakage.
6. There is a stirrer on the electronic heating bath.
7. Stainless steel heater
8. The thermostat displays the heating state.
9. The outer shell is made of high-quality cold-rolled steel plate, and the surface is treated by electrostatic spray, which has good rust prevention and easy cleaning.
10. Safety facilities to prevent overheating and low water levels.
11. Contact control box is very convenient.
12. Microcomputer controller, PID function, digital display temperature (continuous display during test), accuracy 0.1C,Pt100 RTD temperature probe.
13. Fully enclosed compressor refrigeration, large cooling capacity and low noise.


Technical Parameters:

1. Applicable standards: GB/T265, ASTM D445, ISO3104, DIN51366
2. Temperature control mode: imported PID digital display thermostat
3. Temperature control accuracy: normal temperature~-40±0.1ºC
4. Heating method: heating tube heating
5. Machine power: 2.5KW
6. Working unit: 2 tubes
7. Working power supply: AC220V/50Hz
8. Refrigeration method: compressor refrigeration
