GDHG-106B Current Transformer &Voltage Transformer Analyzer

HV Hipot Electric Co., Ltd.
  • After-sales Service：yes
  • Warranty：1 year
  • Max Diameter of Workpiece：3200mm
  • Accuracy Grade：0.5
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load

Base Info

  • Model NO.：GDHG-106B
  • Display：Digital
  • Control：Computer Control
  • Weight：0-100Kg
  • Power Source：AC220V
  • Power Supply：AC220V±10%, 50Hz
  • Output Current：0-1000A
  • Accuracy of Excitation：≤0.5%(0.2%*The Reading+0.3%*Range)
  • Accuracy of Angular Error：4min
  • Accuracy of Ratio Error：0.05%
  • Dimension&Weight：440mm* 340mm* 380mm; 35kg
  • Data storage：3000 grups
  • Output voltage：0-2500Vrms, 5Arms(20A peak)
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030841000
  • Production Capacity：1000PCS,Year

Description

Dimension & WeightDimension: 345mm × 445mm × 380mm
Weight: about 30kg



GDHG-106B Current Transformer &Voltage Transformer Analyzer
GDHG-106B Current Transformer &Voltage Transformer Analyzer
GDHG-106B Current Transformer &Voltage Transformer Analyzer
GDHG-106B Current Transformer &Voltage Transformer Analyzer
