• Model NO.：GDPD-505
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Test and Measurement Instruments
• Measurement channel：2-4PCS independent measurement channel
• Sampling rate：Max. 100MHz of each channel
• Transport Package：Wooden Case
• Specification：SGS, ISO
• Trademark：HVHIPOT
• Origin：Wuhan, China
• HS Code：9030849000
• Production Capacity：5000set,Year

Basic Info.

Model NO. GDPD-505 Control Computer Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Test and Measurement Instruments Measurement channel 2-4PCS independent measurement channel Sampling rate Max. 100MHz of each channel Transport Package Wooden Case Specification SGS, ISO Trademark HVHIPOT Origin Wuhan, China HS Code 9030849000 Production Capacity 5000set/Year

Product Description

General introduction
GDPD-505 is a portable multi-functional PD online detector, which is suitable for transformers and GIS.
The system includes special UHF sensors, 40kHz ultrasonic sensor, HFCT(high frequency current transformer) for GIS, special 150kHz ultrasonic sensor and HFCT for power transformers.

It uses pulse current, ultrasonic and UHF technology, to detect and analyze HF electromagnetic signals and ultrasonic signals of internal transformers and GIS, so that to detect and evaluate the running status ofGIS, transformers.

Features
The main detector is portable design, robust and reliable.
Using 14inch laptop, built-in 20Ah Li-battery. Working up to 4hours without external power supply.
Strong anti-interference ability. Using digital filtering technology, effectively eliminate field interference.
Multichannel data collection. Comprehensive analysis of electromagnetic wave and ultrasonic wave generated by partial discharge.
Easy wiring. BNC port for sensors and detector.
Strong software functions. With PD measurement and analysis, Measurement and analysis of PD repeat discharge times "n", anti-fixed interference, anti-dynamic interference, display mode of ellipse, straight line and sine wave can be selected.
The discharge result is accorded with IEC60720 standard. The display value unit is pc and mV.

Specifications
Measurement channel: 2-4pcs independent measurement channel
Sampling rate: Max. 100MHz of each channel.
Sensitivity: 1pc.
Measurement range: 1pc-10000pc.
Dynamic range: >80dB.
Bandwidth 3dB of measurement frequency band: 10kHz-30MHz.
Digital filter: any setting within 50kHz-30MHz.
Power Supply: AC 220V±10%, 50Hz, power <50W.
Environment temperature: -20ºC-60ºC
Relative humidity: ≤ 95%.
Altitude: ≤3000m.

Sensor specifications
Sensitivity: UHF sensor -75dBm
          Ultrasonic sensor -60dB
          HFCT 10pc
Range: Ultrasonic sensor -60dB-- -18dB
       HFCT  10pc--100nc
Center frequency: Ultrasonic sensor 40kHz
                 Ultrasonic sensor 150kHz
