20kn Testing Force Sensor with Universal Testing Eqauipment
Suzhou Qiantong Instrument Equipment Co., Ltd.- Max Diameter of Workpiece：1200mm
- Mass Scope of Workpiece：100kg
- Type：Strength Testing Machine
- Maxcapacity：20kn
- Accuracy Grade：0.5
- Load Way：Electronic Load
Base Info
- Model NO.：QT-6201 Series
- Loading Method：Dynamic Load
- Display：PC Computer
- Control：Computer Control
- Weight：180kg
- Power Source：AC220V
- Oil Cylinder Position：Electronic
- Fixtures：Customized
- Sensor：America
- Effective Stretching Space：680 mm
- Motor：Taiwan
- Transport Package：Wooden Case
- Specification：840*500*1650mm
- Trademark：Suzhou Qiantong
- Origin：Jiangsu, China
- HS Code：9024800000
- Production Capacity：1000 Set,Year
Description
180kg
The standard accessories:
1,load sensor: USA keli high precision sensor 20kN. 1 set
2,testing software: 64bit test board + Chinese and English interface. 1 set
3,motor control: Taiwan delta B2 servo motor + servo driver 1 set
4,deceleration system: GWD precision reducer 1 set
5,drive rod: Taiwan TBI high-precision ball screw. 2 pieces
6,testing computer; lenovo business computer M2601C 4g rom+HP's printer 1 set
7,test fixture:Customize test fixture according to customer sample 1 set
8,attached files: machine instructions, verification data, warranty, certificate and packing list. for each
Some cooperative brands(This ranking is in no order)
FAQ
Q:Are you a trade company or factory?
A:Our company is a factory and directly sales.
Q:Can your company accept customization?
A: Yes. Our machines can be customized by client.
Q:How to guarantee your after-sales service?
A:Our philosophy is one year warranty and lifetime service. After the warranty period is exceeded, if there is any problem, we will provide support for you in time. (only charge travel expense and parts cost at most.)
Q:What is the language about software?
A:It can switch between Chinese and English.
Q:May the customer not use your company's computer?
A:Sure. But please tell us what type your computer is. We need to confirm your computer can install the software. And we can subtract the price of computer from offer.
Q:What is the different between Type-S and Type-W?
A:Type-S can test multistep experiment, hold loading,bending, yield strength, modulus of elasticity with import upgrade servo, but the Type-W can not do these tests.
