GD-5 Series 22kV 70KV 140kV High Voltage Discharge Rod
HV Hipot Electric Co., Ltd.- Voltage：depend on customer′s requirements
- Package：standard export wooden box
- Transport Package：Standard Export Wooden Box
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan, China
Base Info
- Model NO.：GD-5
- HS Code：9030899090
- Production Capacity：5000set,Year
Description
Basic Info.
Model NO. GD-5 HS Code 9030899090 Production Capacity 5000set/YearProduct Description
GD-5 Series 22kV 70KV 140kV High Voltage Discharge RodThis product has GD-5 70KV, 140KV, 210KV, 280KV, 400KV and other voltage grade insulation parts. The insulating tube is a telescopic tube.
As shown in the diagram: When using, first insert one end of the ground wire into the "current-limiting discharge" jack, and connect the other end to the ground network. When discharging, close the top to the discharge body slowly until it contacts the discharge, and then insert the ground wire into the "short connection" "Discharge" jack, and then close the top and the discharge body slowly until the discharge is contacted to complete the discharge operation.
pay attention:
1. The power of the discharged equipment must be disconnected before discharging.
2. When in use, do not exceed the "armrest limit".
