• Model NO.：HZIR-2000
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC220V
• Name：Sf6 Gas Leak Detector
• Detection Range：0 ~ 1500 Ppm Sf6
• Sensitivity：1 Ppm
• Repeatability：0.3%
• Storage Temperature Rating：- 40 ~ + 70 ºC
• Operating Voltage：220VAC ± 10% 50Hz Continuous Working H
• Internal Pump Fast Response Time：Only 1 Second
• Keyword：Sf6 Gas Leak Detector
• Measuring Principle：Double Wave Dispersive Infrared Spectrometer (Ndir
• Relative Humidity：≤90%Rh
• Transport Package：Wooden Box with Foam Inside
• Specification：CE,ISO,IEC
• Trademark：Huazheng
• Origin：Hebei, China
• HS Code：9027100090
• Production Capacity：500,Month

Main applications 1GIS Switchgear2SF6 circuit breakers, switchgear3SF6-related electrical equipment.

II.Features

Non radioactive material, easy to store and transport
less maintenance (maintenance once every five years) and no wear and tear parts
not bound by moisture content
it has particle filter for protecting the sensor
not bound by the contaminants
internal pump fast response time, only 1 second
no consumables
high sensitivity, can detect the PPMV SF6 gas in the air dropped to 1 ppmv

III.Technical indicators

Measuring principle: double wave dispersive infrared spectrometer (NDIR)
Detection Range: 0 ~ 1500 PPM SF6
Sensitivity: 1 PPM
Repeatability: 0.3%
Storage temperature rating: - 40 ~ + 70 ºC
temperature: - 10 ~ + 60 ºC
relative humidity: ≤90%RH
Sampling method: built-in solenoid diaphragm pumps, automatic suction
Alarm: sound and light alarm
Operating voltage: 220VAC ± 10% 50Hz, AC and DC, continuous working hours
Weight: Console: 2.5 kg, pistol: 0.5kg
 IV.Company Information
HuaZheng Electric Manufacturing (Baoding) Co.,Ltd is the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China.

What's more, our customers come from different countries like America, England, Bulgaria, Brazil, Chile, Malysia, Vietnam and so on.

Our main products are Safety Products, Insulation Oil Tester, Cable Fault Locator, Power Quality Analyzer, High Voltage Generator, High Voltage Capacitor, Testing Transformer and so on.


V. Our Services
1. Good after sales service: Any small problem happening will be solved at the most prompt time;
2. We have many years of experience, we have specializing in fastener;
3. Specifications list is available upon your request
4. Welcome to send enquiry,we will reply soon.If you want to know more,pls feel free to contact us.
5. Prompt shipment with professional documents
6. Packing as your request, with photo before shipment
7. High quality and competitive price
8. All the product quality are under strict controll and offer good service.
9. Our produts now are known by lots of our domestic customers and oversea clients.

VI.Customer Visit


VII.Exhibition
