• Model NO.：GD-264B
• Feature：Automatic, Stable and Reliable, Imported Sample in
• Measurement Range：0.05 Mgkoh,G
• Capacity of Burette：10ml
• Transport Package：Wooden Case for Gd-264b
• Trademark：Gold
• Origin：China
• Production Capacity：100 Piece,Pieces Per Month

Special operation software provides an English windows interface. The man-machine dialog makes it easy to operate.

High resistance input makes the signal stable and reliable

Displaying the curve and result in real time

The test result can be saved as a Word file

The process data can be saved as an Excel file

The curve, result and data can be printed

Automatic liquid compensation. Automatic value set and liquid adding


Specifications:

Product name

Acid number measuring range

≥0.05 mgKOH/g

Potentiometric measurement

(0~1800.0)mV

Capacity of burette

10mL

Minimum titration volume

0.02mL

Precision of burette

±0.1%F•S

Precision of instrument

Meet relevant standard test methods

Power supply

AC(220±11)V ,50±1Hz

Ambient temperature

5ºC~35ºC

Relative humidity

≤80%

Dimension

350*280*178mm(PC is not included)

Net weight

14Kg(PC is not included)

Related Products:

Parameter

GD-251

GD-259

GD-264

GD-264B

Products Name

Alkali Tester

acid and alkali tester

Acid number tester

Automatic acid number tester

Standards

SH/T0251, ASTM D2896

GB/T 259

GB/T264,GBT258,GB/T599

GB/T264,GB7599,GBT7304,GB/T18609,ASTM D664

Test sample

Petroleum products and used petroleum products and additives

Liquid petroleum products, additives, Lubricant greases, paraffin and waxy components

Gasoline, kerosene and diesel oil without any ethyl liquids and other petroleum products

Transformer oil, turbine oil, anti oil, diesel, gasoline and other petroleum products

Features

Manual

Manual

Manual

Automatic,stable and reliable, imported sample injector

Measurement range

pH:(0~14.00)pH

mV:(0~±1999)mV

0~14.00PH

--

≥0.05mgKOH/g;

(0~1800.00)mV

Measurement precision

pH:±0.01;

mV:0.1%F.S

±0.01pH

0.02ml

±0.1% F.S

Dimension

280*200*130mm

(only the main machine)

270*160*600mm

(Including the stand column)

270*160*600mm

(Including the stand column)

350*280*178mm

(PC is not included)

Company  Information:

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.

We mainly design and manufacture the petroleum testing instrument
After several years' development, our products have become high intelligent and wide coverage. And our company has become one of the leading manufacturer of petroleum testing instrument .
