Medical Supplies Packaging Gypsum and Plaster Products Wvtr Water Vapor Transmission Rate Analyzer (ASTM E398)
Pubtester Instruments Co., Ltd.- After-sales Service：on Line
- Warranty：12 Months
- Test Method：Gravimetric Method
- Test Range：0.1~10,000 G,M2 24h
- Resolution：0.0001 G
- Temperature Range：5~ 95 Degree
Base Info
- Model NO.：WVTR-W6
- Temperature Accuracy：0.1 Degree
- Air Velocity：0.5~2.5 M,S
- Specimen Thickness：3 mm
- Test Area：33 Cm2
- Specimen Size：74 mm
- Trademark：Pubtester
- Origin：Shandong, Jinan
- HS Code：9024800000
- Production Capacity：10 Sets,Quarter
Description
90Kg
Note 1: Refers to the relative humidity on both sides of the film, the humidity in the test chamber is 10%RH-30%RH.
Note 2: Refers to the relative humidity on both sides of the film, the humidity in the test chamber is as follows:
Temperature:15ºC-40ºC,Humidity:10%RH-98%RH
Temperature:45ºC, Humidity:10%RH-90%RH
Temperature:50ºC, Humidity:10%RH-80%RH
Temperature:55ºC, Humidity:10%RH-70%RH
Standards
ASTM E96, ASTM D1653, GB 1037, GB/T 16928, YY/T0471, TAPPI T464, ISO 2528, DIN 53122-1, JIS Z0208, YBB 00092003
Configuration
Standard configuration: Instrument, Professional Software, Test Dishes, Desiccant Tube, Automatic Moisture Filter, Standard Weight, Communication Cable, Round Sample Cutter, Valve Set and Reference Film
Optional configuration:Air Compressor, Desiccant, GMP software
Note:
1. The gas supply port of the instrument is Φ6 mm PU tubing;
2. Customers will need to prepare for gas supply and distilled water.
FAQ
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
