GDZRC-40U DC Resistance Test Transformer Winding Analysis Instrument

HV Hipot Electric Co., Ltd.
  • After-sales Service：yes
  • Warranty：1 year
  • Mass Scope of Workpiece：<900kg
  • Type：DC Winding Resistance Tester
  • Accuracy Grade：0.2
  • Load Way：Electronic Load

Base Info

  • Model NO.：GDZRC-40U
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control
  • Weight：15kg
  • Power Source：AC220V
  • Output current：<5mA, 2.5A, 5A, 10A, 20A, 40A
  • Min. resolution：0.1μΩ
  • Operation temperature：0~40ºC
  • Humidity：<90%RH (no condensing)
  • Size：325mm×240mm×275mm (L×W×H)
  • Transport Package：Standard Export Wooden Box
  • Specification：325mm*240mm*275mm
  • Trademark：HV Hipot
  • Origin：China(Mainland)
  • HS Code：9031809090
  • Production Capacity：4000sets,Year

Description

Output current

<5mA, 2.5A, 5A, 10A, 20A, 40A

Min. resolution

0.1μΩ

Measurement range

50μΩ~500mΩ

100μΩ~1Ω

500μΩ~2Ω

1mΩ~4Ω

2mΩ~8Ω

10Ω~20KΩ

40A

20A

10A

5A

2.5A

<5mA

Accuracy

±(0.2%+2digits)

Operation temperature

0~40ºC

Humidity

<90%RH (no condensing)

Size

325mm×240mm×275mm (L×W×H)

Weight

15kg (without test wire)
