• Model NO.：HJ-65
• Power Source：AC220V
• Technical Features：Description of Technological Advancement
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-65 Power Source AC220V Technical Features Description of Technological Advancement Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Introduce
The Japanese standard JIS rain test box is used to test the IPX5 and IPX6 waterproof grades of the products. The test samples include electronic components, outdoor lamps, mobile phone casings, auto parts, etc. The system can be operated remotely, which is convenient and quick.

Application background:
The damage to products and materials caused by natural water (rainwater, seawater, river water, etc.) causes incalculable economic losses every year. The damage caused mainly includes corrosion, fading, deformation, strength reduction, expansion, mildew, etc. In particular, electrical products are prone to fire due to short circuit caused by rain. Therefore, it is an indispensable key procedure to conduct the shell protection water test for a specific product or material.

Application areas:
Outdoor lamps, household appliances, auto parts and other electronic and electrical products.

Features
1. Applicable to the sprinkling test of R1/R2/S1/S2 in JIS D0203.
2. The chassis and sample turntable are made of SUS304# stainless steel to ensure long-term use without rust.
3. It has its own water storage tank. The water level float valve is installed in the water tank to automatically control the water intake, and there is a low water level control to prevent the water pump from being damaged due to lack of water.
4. The electrical part of the turntable is fully sealed to prevent water leakage.
5. Turntable drive: using domestic high-quality stepping motor, the speed and angle can be set (adjustable) on the touch screen, steplessly adjustable within the standard range, and can automatically control the forward and reverse rotation.
6. The water pressure of the Japanese standard coil can be set on the touch screen.
7. The daily standard rotary tube drive adopts domestic high-quality stepping motor, and the swing tube speed and angle are adjustable (set directly on the touch screen). The daily standard rotary tube speed machine can be controlled at 23 rpm/1 minute.
8. R1, R2, S1, S2 can work individually or at the same time.


Outer dimensions of the device	About length 1450* depth 1220* height 1860mm
Work box size	length 1000* depth 1000* height 1150mm
Sample Turntable Dimensions	Diameter 400mm
Turntable load	50KG
R1R2 Sprinkler Test Coil	Customized in strict accordance with the requirements of  the sprinkler test drawings of JIS D0203
Spray hole	2
S1S2 Water Spray Test Coil	Customized in strict accordance with the requirements of  the water spray test drawings of JIS D0203
Number of spray holes	40
Protective function	Leakage protection, water shortage protection, short circuit protection

The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.
Hongjin's services:
If you encounter any problems during future testing, we promise we will reply you within 48 hours and provide a solution within 3 working days. We can provide operation video and English operation manual. We can provide video conferencing.
1. Pre-sales service
    --24-hour online service for your consultation.
    -- Help with choosing the right model, and a range of services, people, advice.
   --Provide laboratory planning and pre-sales technical guidance.
2. Intermediate service
    -- give you the best offer
    --Provide discounts on multiple sets of orders
    -- Do the customer's request:
    --Choose a payment term that is convenient for you.
    --Prompt production and delivery, keep you informed.
    -- Invoice value can be provided according to your needs to reduce tax.
3. After-sale service
   --1 year warranty service and lifetime maintenance.
   --Technical engineers can provide 24-hour after-sales guidance.
   --Replacement of some parts
   --Remote control technical consultation
   --Machine lifetime maintenance service
4. Commitment:
We will sign a letter of commitment at the same time as signing the contract, which will increase your confidence in us.
5. Good packaging:
Simulation animation customers cover with bubble film before putting them into wooden boxes, which not only has good shock absorption, impact resistance, heat sealing, but also has the advantages of non-toxic, odorless, moisture-proof and corrosion-proof, and good transparency.
