Highly-Pressure Accelerated Aging Test (HAST) Chamber Saturated Type
Guangdong Komeg Industrial Co., Ltd.- After-sales Service：24 Hours on Line Services
- Power Supply：380V
- Certification：CE, TUV, ISO
- Warranty：1 Year
- Temp. Range：105c~135c
- Chamber Volume(L)：43 Liters
Base Info
- Model NO.：PCT-35
- Inner Size (D*W*H))：Diameter 350 mm*D (Depth) 450mm
- Exterior Material：Stainless Steel Plate
- Cooling Mode：Natural Cooling or Air Purging Type
- Temp Change Rate：25c~135c, Average 45 Min
- Outer Dimension：About W730 mm*H1630 mm*D1300 mm
- Humidity Range：Std Saturation Test Mode: 100%Rh
- Transport Package：Strong Plywood Case for Long Journey Delivery
- Specification：Standard and customs made
- Trademark：KOMEG
- Origin：Dongguan, China
- HS Code：90321000
- Production Capacity：1000 Sets,Year
Description
- Structure
Round inner box, stainless steel round test inner box structure, in line with industrial safety container standards, can prevent dew condensation design during test
Automatic access control, round door automatic temperature and pressure detection security access control lock control, patented safety door handle design, the tester will be back pressure protection when the box is greater than normal pressure.
Patented packing, the greater the pressure inside the box, the back pressure of packing will make it more tightly combined with the box, which is completely different from the traditional extrusion type, which can extend the packing life.
The circular lining and the stainless steel circular lining design can avoid the direct impact of the vapor latent heat.
Precise design, good air tightness, low water consumption, continuous water supply for 200h each time
The vacuum action before the start of the experiment can extract the air in the original box and suck in the new air filtered by the filter core (partical<1 micorn) to ensure the purity inside the box.
Critical point LIMIT mode automatic safety protection, abnormal cause and fault indicator display
HIGHLY-PRESSURE ACCELERATED AGING TEST(HAST) CHAMBER SATURATED TYPE
Photos show
HAST accelerated life test machine(Extreme humidity test chamber) is designed to speed up the test process and shorten the life test time of the product or system under high environmental stress (such as temperature) and working stress (voltage, load, etc. applied to the product). With the improvement of semiconductor reliability, most of the former semiconductor devices can withstand the long-term THB test without failure, so the test time for determining the quality of the finished product is also increased accordingly. In order to improve the test efficiency and reduce the time, the latest is adopted.
Features:
1.Large-capacity water tank, long test time, fully automatic water supply, the test is not interrupted;
2.A sample signal application terminal that matches the number of samples;
3.It adopts 7-inch true color touch screen, has USB curve data download function, RS-485 communication interface;
4.Adopt high-efficiency vacuum pump to achieve high purity and saturated steam in the tank;
5.One-piece silicone door gasket, good gas density and long service life;
6.Special equipment can be customized according to different needs of customers (such as: inner box size and deviation can meet different test needs of customers);
7.Customized product racks can be customized according to customer's product appearance and size;
8.Corresponding to IEC60068-2-66 conditions, with dry and wet bulb temperature sensors that directly measure the temperature and humidity inside the box;
9.It has the functions of slow pressure reduction, exhaust and drainage, and avoids the rapid change of pressure temperature after the end of the test to ensure the correct test results.
10.Over-temperature protection: When the temperature inside the pot is too high, the machine will sound an alarm and automatically cut off the heating power;
11.Anti-scalding protection: made of special materials to prevent the operator from getting hot;
12.Over-pressure safety protection: When the pressure in the pot exceeds the maximum working value, the automatic exhaust pressure relief, extreme over-pressure relief protection, manual emergency pressure relief protection;
13.Mishandling safety device: If the pot door is not closed, the machine will not start;
14.Fault abnormality shut down the whole machine power failure processing and fault prompt
- Structure
