• Model NO.：GW-017
• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Electric Control
• Packaging：Wooden Case
• Export Markets：Global
• Model No：Gw-017
• Lamp：D65;Tl84;Cwf;F,a;UV;U30
• Power：AC 220V,50Hz
• Dimensiom of Inter Cabinet：60*45*35cm
• Volume：67*55*62.5cm
• Transport Package：Standard Export Safety Packing
• Specification：10kg
• Trademark：Great Win
• Origin：China
• HS Code：9024800000
• Production Capacity：500 Pieces,Year

Basic Info.

Model NO. GW-017 Loading Method Dynamic Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Electric Control Packaging Wooden Case Export Markets Global Model No Gw-017 Lamp D65;Tl84;Cwf;F/a;UV;U30 Power AC 220V,50Hz Dimensiom of Inter Cabinet 60*45*35cm Volume 67*55*62.5cm Transport Package Standard Export Safety Packing Specification 10kg Trademark Great Win Origin China HS Code 9024800000 Production Capacity 500 Pieces/Year

Product Description

Color assessment cabinet(six light source)/Color test machine (GW-017 )

Brief introduction:
Because of the light source, intensity of illumination and the environment is different, to cause the color conformity is difficult or occurred misjudgment on the color matching of product. So the light boxes designed specifically to provide standard, objective luminosity, make the precise control on the quality management of raw materials, and products color comparison.

Technical Specifications:

Model	GW-017 Color assessment cabinet(six light source)
1,D65   standard of Artificial Daylight
Color temperature:	6500K  Power:18W x2
2,TL84   Europe, Japan, China store light source
Color temperature:	4000K Power:18W x2
3,CWF   cool white store light source (Cool White Fluorescent)
Color temperature:	4200K Power:18W x1
4,F/A   Family hotel lamp,sun-setting light ,yellow light source.
Color temperature:	2700K Power:40W x4
5,UV   UV light source (Ultra-Violet)
Wavelength:	365nm Power:18W x1
6. U30  others USA shop light source
Color temperature:	3000k power:18W x2
Dimension of inner cabinet:	65*45*35cm
Power: 1∮,AC220V,1.5A         Net weight:	33KG
Volume:	67*55*62.5cm

Standard for:

JIS - Z8724



What about the product quality?
For our products, each instrument must be carried out 100% quality calibration and test when delivery goods. With CE certificate, we are very confident in our products, and we will pack them with safety wooden case to protect the machine when transport oversea.

What about usage of the machine?
We will also give your professional guidance(Product operating manual and video), each products comes with a USB flash drive which have all the details.

What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support, we can help them solve their problem through email, video meeting. We also can provide door to door service, but customer need to bear the travel fees.

What about standards support?
We are strictly following different international standards such as EN, ISO, ASTM, AATC, JIS, GB ect, and had been recognized by SATRA, CSA international standard agency.
