• Model NO.：GD-4508G
• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Top
• Transport Package：Wooden Case
• Specification：600mm*460mm*430mm
• Trademark：GOLD
• Origin：China
• HS Code：9031809090
• Production Capacity：200unit,Month

 Power supply:  AC(220±10%)V,50HzMeasurement distance:  1.5m(±10mm)Heating power:  3200Wheating method:  Electric heaterBath liquid circulation:

Strong magnetic circulation pump circulating bath.

Temperature control:

 5 ° C ~ 50 ° C adjustable, digital display, temperature display resolution of 0.01 ° C.

Temperature control accuracy:

± 0.1 ° C.Tensile speed:  (10~50)mm/min,stepless adjustment. accuracy: ±1mm

Measurement accuracy:

± 1mm.

Ductility display:

The display is displayed in real time. Duty record:

(1) Record by wireless delay recorder (remote control)

(2) Record by the touch screen "Temperature Record 1/2/3" button.

Tensile test: Range: (0~300)N, accuracy: ±1N, resolution: 0.1NData output:

(1) Communication port RS232

(2) Printed by micro-printer

Refrigeration:

Compressor refrigeration.

Ambient temperature:  (-10~+35)ºCRelative humidity:  ≤85%Maximum power consumption:  ≤5600WOverall dimension:  2365mm*530mm*950mm

 (length × width × height).


• Gold Equipment Service:

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and

solution provide within 3 working days.

We can offer operation video and English operation muanual. We can provide video-con.

Onsite Service:

1.Device installation; 2.Equipment Operation Test Technology training;3.Daily maintenance and maintenance of equipment

Free technical training for visiting factories

24-hour Online contact

Free software upgrades

Free information:

1.Product Instruction;2.Product operation instruction/video;3.Experiment Test (test application, test report)

Device Problem Handling:

1. Social media 24 hours online communication;2. Mail Seamless Docking;3. Video Conferencing;4. Artificial door-to-door service



• Exhibition

We have developed sales channels in many countries such as UAE, Saudi Arabia, Iran, Malaysia, Thailand, Pakistan,

India, Germany, Belgium, USA, Mexico, Kenya,

Nigeria, South Africa and other countries worldwide. And we have gained strong advantage and high reputation in international market.

After several years' development, our products have become high intelligent and wide coverage.
And our company has become one of the leading manufacturer of petroleum testing instrument and electrical testing instrument.

Brazil ANALITICA LATIN AMERICA 2017 2017 Photos Show


• Packing

Goods are packed in veneer case, which is firm and safe for oversea shipment.
