• Model NO.：ut595
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC220V
• Name：Ut595
• Insulation Resistance：0.05mΩ~1000mΩ
• Test Voltages：250V,500V,1000V
• Low Resistance Continuity Test：0.00Ω~199Ω
• Test Current：0.00~2Ω: >200mA
• Line Impedance：0.01Ω~2000Ω
• Loop Impedance：0.01Ω~2000Ω
• MOQ：1
• Function：Loop Testers Ut595
• Transport Package：Standard Carton, Box
• Specification：CE,ISO,IEC
• Trademark：HuaZheng
• Origin：Baoding, Hebei
• HS Code：9030320000
• Production Capacity：1000 PCS,Month

SpecificationsRangeBest AccuracyModel UT595Insulation Resistance (Ω)Test Voltages250V/500V/1000V±10%250V0.05MΩ~250MΩ±(5%+5)500V0.05MΩ~500MΩ1000V0.05MΩ~1000MΩShort-Circuit Current<2mA√Low Resistance Continuity Test(Ω)Range0.00Ω~199Ω±(2%+5)Test Current0.00~2Ω:   >200mA√Line Impedance (Ω)Range0.01Ω~2000Ω±(5%+5)Operational Voltage(Freq.)195V~440V(45Hz~65Hz)√Test Current20A√PFC  Range0KA~26KA√Loop Impedance (Ω)Range0.01Ω~2000Ω±(5%+5)Operational Voltage(Freq.)195V~253V(45Hz~65Hz)√Test Current20A√PFC  Range0KA~26KA√Loop Impedance Without Tripping(Ω)Range1.00Ω~2000Ω±(5%+5)Operational Voltage(Freq.)195V~253V(45Hz~65Hz)√Test Current15mA√PFC  Range0KA~26KA√RCDOperational Voltage(Freq.)195V~253V(45Hz~65Hz)√Test Current10mA/30mA/100mA/300mA/500mA±10%Trip Time×1/2 *I n  Range:0ms~2000ms±(5%+5)×1 *I n  Range:0ms~300ms±(5%+5)×1 *I n Range:0ms~500ms(Selective Countdown)±(5%+5)×2 *I n  Range:0ms~300ms±(5%+5)×2 *I n Range:0ms~500ms(Selective Countdown)±(5%+5)×5 *I n  Range:0ms~40ms±(5%+5)Phase Sequence TestOperational Voltage(Freq.)100V~440V(45Hz~65Hz)√IndicationOrder:L1→ L2→ L3 Positive change;L1→ L3→ L2 To reverse√RCD Measurement RAMP SlopeTest Current Range10mA/30mA/100mA/300mA/500mA±10%AC Voltage (V)Range0V~440V±(5%+2)Frequency Response 45Hz~60Hz√Resolution1V√FeaturesDisplay Count 9999Auto Power Off √Low Battery Indication √Data Logging √LCD Backlight √Auto Half-wave Test √RCD Countdown Measurement30 Seconds√RCD Half-wave Test √Phase Switch(RCD)0°and 180°√General Characteristic Power1.5V Batteries(LR6) X 6 LCD Size125mm X 37mmProduct ColorRed and Grey       Product Net Weight1000g Product Size210mm X 175mm X90 mm  Standard AccessoriesBatteries, Test Lead (1 x Green, 1x Black, 1 x Red), Specialized Test Lead,  Remote Control Test LeadStandard Individual PackingGift Box, Tool Box, User ManualStandard Quantity Per Carton4 PCsStandard Carton Measurement510mm X 330mm X 300mm (0.051CBM Per Standard Carton)Standard Carton Gross Weight15Kg


III. Detailed Photos


IV. Company Information

HuaZheng Electric Manufacturing (Baoding) Co., Ltd is the supplier of the State Grid in China. It means we are the supplier of the Chinese Government. And our products spread throughout the whole China.

What's more, our customers come from different countries like America, England, Bulgaria, Brazil, Chile, Malaysia, Vietnam and so on.

Our main products are Digital Multimeter, Insulation Oil Tester, Cable Fault Locator, Power Quality Analyzer, High Voltage Generator, High Voltage Capacitor, Testing Transformer and so on.

V. Our Services

1. 24 hours hot line.
2. We supply OEM service.
3. Our engineers available to service machinery overseas.
4. We can produce the products as your request.
5. To produce high quality products, services to the public.
6. To act quickly, seize the opportunity, continuous innovation, the pursuit of excellence.

VI. FAQ

1. Q: Are you a factory or trading company?
     A: We are a factory.

2. Q: Where is your factory located? How can I visit there?
     A: Our factory is located in Baoding city, Hebei province, China.
      You can go to Baoding by train directly.
      All our clients, from home or abroad, are warmly welcome to visit us!

3. Q: How can I get some samples?
     A: We are honored to offer you samples.

4. Q: How does your factory do regarding quality control?
 A:Quality is priority.we always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained BV, CE,ISO, SGS authentication.

5. Q: May I send deposit by Paypal?
    A: yes, for the small amount, we accept paypal.

6. Q: May I know your payment term?
     A: Mostly, we work with: FOB / CNF / CIF or EX-WORK.
      100% by T/T before delivery. Small amount by T/T or Western Union or Paypal are acceptable.

7. Q: May I know your delivery term?
 A: Depending on your quantity, for goods we have in stock, Delivery takes 2 days to comply with your
request.
      For Regular order, delivery takes between 20-30 days.

VII. Customer Visit

VIII.Exhibition
