• Model NO.：SXDJ
• Control：Manual,Auto at Customized
• Weight：500-1000Kg
• Power Source：at Customized
• Oil Cylinder Position：Under
• Control Mode：Manual,Computer
• Test Capacity：0-10000kw
• Motor：AC,DC
• Test Items：at User′s Option
• Transport Package：Plywood Case
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030339000
• Production Capacity：1000 Units

Main Testing Items:
 Electric StrengthMeasuring conditionInsulation ResistanceCold ResistanceLow Starting CurrentLocked-rotor CurrentNo-Load PowerNo-Load CurrentLeakage CurrentTurn-To-Turn Insulation
Partial of Specification for reference using only:General Information.This system is mainly applied for the routine testing on 300KW three phase motor.
The system is consisted by two parts:

• Front power source

With 300kW regulator and 300kW transformer as frond system power source.

• Measuring control.

System measuring control part adopts high-precision electrical parameters test unit to meet the precision electrical measurement requirements on various models/levels motors.

• Main components using well-known brands: Schneider.

System features:

• To complete the 300kW /110V/240V/415V motor no-load test, no-load loss, three-phase voltage unbalance test, DC winding resistance test, turn-to-turn voltage withstand test, insulation resistance and power frequency voltage withstand test.
• Measurement parameters display, measurement parameters menu display, parameter setting.
• All the test data can be displayed and printed out.
• High quality SCM processor, unique scientific algorithms for data computing and processing, analog-digital conversion using high-speed fast A/D converter, the analog signal conditioning also uses the current advanced processing technology, TO provide the necessary conditions for the high performance, high precision and high reliability of the system.
• PLC & manual controlled. The multilevel menu can guide you complete the test step by step.
• Fully English interface, easy to operate.


Please contact us for more details. Thank you!
