Manual Spring Tension and Compression Testing Machine ASTM
Jinan Kason Testing Equipment Co., Ltd.- After-sales Service:24 Hours Technical Supply
- Warranty:12 Months
- Max Diameter of Workpiece:<500mm
- Mass Scope of Workpiece:<900kg
- Type:Strength Testing Machine
- Maxcapacity:<1000KN
Base Info
- Model NO.:TLS-S series
- Accuracy Grade:1
- Load Way:Electronic Load
- Loading Method:Static Load
- Display:Digital
- Control:Manual Control
- Weight:100-500Kg
- Power Source:AC220V
- Oil Cylinder Position:None
- Delivery Time:3 Days After Get Tt Payment
- Transport Package:Standard Export Packing
- Specification:610*360*980mm
- Trademark:HST
- Origin:China
- HS Code:9031809090
- Production Capacity:1000 Sets Per Month
Description
Basic Info.
Model NO. TLS-S series Accuracy Grade 1 Load Way Electronic Load Loading Method Static Load Display Digital Control Manual Control Weight 100-500Kg Power Source AC220V Oil Cylinder Position None Delivery Time 3 Days After Get Tt Payment Transport Package Standard Export Packing Specification 610*360*980mm Trademark HST Origin China HS Code 9031809090 Production Capacity 1000 Sets Per MonthProduct Description
Manual spring tension and compression testing machine ASTMApplication:
This machine is based on the country's spring and compressive tester standards of technical requirement is made, professional design of automatic control and data acquisition system, realized the data acquisition and control process full digital adjustment. Can the compression spring, dish above precision extension spring, spring, spring, leaf-spring tower, card of spring, spring, spring, composite, gas springs, die spring, and special spring precision tension of the spring, stress, displacement, stiffness and strength test and analysis.
Main specification:
Max test force(N) | 50 | 100 | 200 | 500 | 1000 | 2000 |
Test force accuracy(N) | 0.005 | 0.01 | 0.02 | 0.05 | 0.1 | 0.2 |
Displacement accuracy (mm) | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 |
Tensile test max distance between two pressure plate(mm) | 220 | 220 | 220 | 220 | 270 | 270 |
Compression test max distance between two pressure plate(mm) | 220 | 220 | 220 | 220 | 270 | 270 |
Plate size(mm) | 60 | 60 | 60 | 60 | 110 | 110 |
