• Model NO.：GDHG-108A
• Weight：22Kg
• Power Source：AC220V
• Power supply：AC220V±10%, 50Hz
• Output voltage：0-2500Vrms
• Accuracy of excitation measurement：≤ 0.4% of the reading+0.6% of the range
• Dimension：440mm*360mm*340mm
• Output current：5Arms(20A peak)
• Transport Package：Standard Export Wooden Box
• Specification：380mm * 240mm * 180mm
• Trademark：HV Hipot
• Origin：China
• HS Code：9030849000
• Production Capacity：5000set,Year

Item

Parameter

Power supply

AC220V±10%, 50Hz

Output voltage

0-2500Vrms

Output current

5Arms(20A peak)

Accuracy of voltage current characteristic

±0.5%

Secondary winding resistance measurement

Range

0.1~300Ω

Accuracy

±0.5%

Secondary actual burden measurement

Range

5VA~1000VA

Accuracy

±0.5%

CT/PT angular error measurement

Accuracy

±4min

Resolution

0.1min

CT/PT ratio error measurement

Accuracy

≤0.05

Resolution

0.1

CT ratio measurement

Range

1-10000

Accuracy

±0.5%

PT ratio measurement

Range

1-10000

Accuracy

±0.5%

Operation  environment

Temperature: -10ºC-40ºC, Humidity: ≤90%, Altitude: ≤2000m

Dimension & Weight

Dimension: 380mm × 240mm × 180mm

Weight: ≤18Kg
