Komeg Save Space Design Multi-Zone High and Low Temperature Test Chamber

Guangdong Komeg Industrial Co., Ltd.
  • After-sales Service：24 Hour on Line Servics
  • Warranty：1 Year
  • Type：Material Testing Machine
  • Accuracy Grade：0.5
  • Loading Method：Dynamic Load
  • Display：Digital

Base Info

  • Model NO.：KMT-580L
  • Control：Computer Control
  • Weight：100-500Kg
  • Power Source：AC380V
  • Temp. Range：-40oc~+150oc
  • Inner Materials：304 Mirror Stainless Steel
  • Temp. Constancy：+,-0.5oc
  • Heating and Cooling Rate：3c,Min
  • Temp. Uniformity：+,-2.0oc
  • Temperature Fluctuation：+,-0.5oc
  • Heat up Time：-40oc~+100oc Within 45mins
  • Pull Down Time：+20 Oc~-40 Oc Within 20mins
  • Refrigeration System：Hermetic Compressor, Cascsde Refrigeration CFC
  • Equipment Power：9.5kw
  • Transport Package：Strong Plywood Case, Meet International Standard
  • Specification：Standard and Customized
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets Per Yesr

Description

ModelKMT-408L408L chamber volumeTemp. range -40°C ~150°C Display resolution0.1°CTemperature stabilityHigh±0.5°C ,low ±1.0°CTemperature uniformity ±2.0°CHeat up time -40°C ~+100°C,within 45 minPull down time +20°C ~-40°C,within 60 minHumidity range20~98%R.H,(standard),   '10~98%R.H,(with humidifier)Humidity constancy±2.5%R.HHumidity uniformity±3.0%R.HInterior Dimension(mm)700W*750H*800D Exterior Dimension(mm)980W*1940H*1740DInterior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolTotal power  7KW(heater 3KW included)Max current17AWater Consumption1L/hrAmbient Temp.+5°C ~+35°C Power Supply AC 380V±10%50Hz ,3 phase 4 wires +Ground WiresWeight 420KGSight window size460*560mmSample holder 2 pcsFittingscable port(portΦ50mm)*1, chamber lamp*1, power cable *2mSafety device  (standard)No fuse breaker,over pressure,over heat&over current protect,over temp. protect, over load protect for blower, dry heat protect Control SystemBalanced Temperature & Humidity Control (BTHC)SystemRefrigeration systemAir Cooled (Water Cooled is option)Hermetic compressor  Hermetic compressor
Single stage refrigeration system,
CFC-Free refrigerant(HFC-507/HFC-23)CFC-Free refrigerant(HFC-507/HFC-23)Controller7-inch LCD Touch Screen panel                                                                        Operation model :Program or fix point runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesNote: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available

Komeg Save Space Design Multi-Zone High and Low Temperature Test ChamberKomeg Save Space Design Multi-Zone High and Low Temperature Test ChamberKomeg Save Space Design Multi-Zone High and Low Temperature Test ChamberKomeg Save Space Design Multi-Zone High and Low Temperature Test ChamberKomeg Save Space Design Multi-Zone High and Low Temperature Test Chamber
After-sale service

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.
