• Model NO.：GD-0719-1
• Loading Method：Dynamic Load
• Display：Digital
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Transport Package：Wooden Case
• Specification：620mm*460mm*355mm
• Trademark：GOLD
• Origin：China
• Production Capacity：200units,Month

 Standards:  industrial standard T0719-2011 in  JTG E20-2011Grinding rate:   (42±1)times/min(one-way) Test wheel movement distance:   230mm±10mm Rubber hardness:       78±2 (international standard hardness) Loading device:  0.7MPa±0.05Mpa (at 60 °C), adjustable range 0.5~1.2 (Mpa)a Displacement measuring range:     0mm~30mm Displacement measuring accuracy:    ±0.01mm Wheel track test time:    60 minutes~240 minutes.

Control range of the incubator:

 room temperature ~ 80 ° C (can be set arbitrarily)

 Work mode: water immersion test and non-immersion test Temperature measurement accuracy:  ±0.1ºC Environment control accuracy:

±1 °C

Test mode temperature control accuracy:

 ±0.5ºC Temperature measurement channels:  2 channel

The number of test pieces that can be made at the same time:

 1  Number of health care of the test piece:  3  Roller motion mode:  Test wheeled Power supply AC380V, 50Hz, 10A, three-phase four-wire system, with a neutral line

Dimensions of the whole machine:

1520mm × 770mm × 1700mm (length × width × height) 350kg



Test die size:

300mm × 300mm × 50mm (standard) / 30mm ~ 100mm (adjustable)



Workshop

Chongqing Gold Mechanical&Electrical Equipment Co., Ltd is a professional manufacturer of Petroleum Products test kits and

electrical testing equipment in China. Our products are sold to most countries in the world and they are highly popular because of our good

quality and after-sale service.




At present, there are more than 150 employees, of whom more than 70% are technical personnel with a college

degree or above. With strong technical force and strong development, new products have been launched continuously.


Exhibition



We have developed sales channels in many countries such as the UAE, Saudi Arabia, Iran, Malaysia, Thailand, Pakistan,

India, Germany, Belgium, the USA, Mexico, Kenya, Nigeria, South Africa, and other countries worldwide. And we have

gained a strong advantage and high reputation in the international market.

After several years' development, our products have become highly intelligent and wide coverage.
And our company has become one of the leading manufacturers of petroleum testing instrument and electrical testing

instrument.

Packing

Goods are packed in veneer case, which is firm and safe for overseas shipment.

Please feel FREE to contact us if you have any needs. And welcome to visit our OFFICIAL WEBSITE at:

http://chinainstrument.en.made-in-china.com
