20kV AC/DC Withstand Voltage Tester
HV Hipot Electric Co., Ltd.- Input：110V or 220VAC, ±10%, single phase
- Output voltage：20KV(AC,DC)
- • Output voltage accuracy：± 5% ± 3 digits
- Cut-off current：AC,DC 0.5 ~ 20mA
- Display mode：digital display
- • Cut off current accuracy：± (5% ± 0.1mA)
Base Info
- Model NO.：GD2013
- Test time：0 ~ 120s and manual control
- Usage：Voltage withstand testing machine
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9030332000
- Production Capacity：10000 Pieces,Year
Description
Basic Info.
Model NO. GD2013 Test time 0 ~ 120s and manual control Usage Voltage withstand testing machine Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 10000 Pieces/YearProduct Description
General InformationGD2013 Withstand Voltage Tester is mainly used for withstanding voltage testing of electronic components, electronic equipment, wires and cables, labor protection appliances, etc., and also used as polarization power supply, etc. The circuit design of this series of products is advanced and reliable. The design of the instrument is serialization and combination, which can modify the parameters and functions according to the user's requirements, and widely meet the needs of various users.
Specification
- Power supply: AC 220V ± 10%, 50Hz ± 5Hz
- Output voltage: AC/DC 20kV
- Cut off current selection: AC/DC 0.5 ~ 20mA
- Output voltage accuracy: ± 5% ± 3 digits
- Cut off current accuracy: ± (5% ± 0.1mA)
- Test time: 0 ~ 120s and manual control
- Working environment: temperature: 0 ~ 35 ºC
- Humidity: ≤80% RH
- Atmospheric pressure: ≤86kpa ~ 106kpa
