Test Instrument

Factory Direct Melt Flow Indexer for PVC Index

Jinan Chenji International Trade Co., Ltd.
  • After-sales Service:Whole Life
  • Certification:TUV
  • Power:Electronic
  • Warranty:1 Year
  • Style:Desktop
  • Application:School, Lab

Base Info

  • Time Range:0-999s
  • Temperature Control Range:50-450degree
  • Accuracy:± 0.2 ºC
  • Resolution:0.1 ºC
  • Sensor Measurement Range:0 - 40mm
  • Accuracy 1:± 0.05mm
  • Dimensions:550 × 370 × 600mm
  • N.W.:25kgs
  • Weight of The Host:21.6 Ks
  • Transport Package:Standard Package
  • Specification:500*300*800
  • Trademark:Chenji or OEM
  • Origin:China Jinan or Others


Barrel parameters

Inner hole 9.55±0.025mm

Pistons parameters

Piston head:  9.475±0.015mm

Piston length



Extrusion hole 1=2.095±0.005mm

Temperature parameter

With intelligent temperature control instrument, with four pairs of significant temperature setting control, PID parameters can be automatically set, precision up to ± 0.1 degree centigrade

Temperature range


Temperature rating

±0.2 ºC

Display resolution


Maximum consumption

< 600W

Temperature recovery time

less than 4 min.

Weight accuracy


Basic configuration

0.325kg, 1.2kg, 2.16kg, 3.8kg, 5.0kg, 10.0kg, 12.kg, 21.6kg

Loop distance from up and down


Control precision

± 0.1mm

Times of cutting the material

 0~10 times

Material cutting interval

0~999s(set reference Table 2)

Barrel temperature time

15 min.

Material be installed

1 min

Material sample temperature recovery time

4 min.

When binder set
