Test Instrument

DH-MI-BP Touch Screen Melting Flow Index Test Equipment With Best Quality

DongGuan HongTuo Instruments Co., Ltd.
  • Type:MFI Testing Machine
  • Charging Cylinder Diameter:Φ9.550±0.025mm
  • Charging Cylinder Length:152±0.1mm
  • Piston Rod Diameter:9.475±0.015mm
  • Delivery Time:2-7 days
  • Testing Before Delivery:Yes

Base Info

  • Model NO.:DH-MI-BP
  • After-sale Customer Service:Yes
  • Transport Package:Standard Exporting Wooden Package
  • Trademark:DahoMeter
  • Origin:Dongguan, China
  • HS Code:9027809900
  • Production Capacity:300 Sets,Month

Description

Testing resultMassMass and volumeMassMass and volumeMass and volumeMFRMFR and MVRMFRMFR and MVRMFR and MVROutlet diameterΦ2.095±0.005mm,Outlet length:8.000±0.025mmLoading cylinder diameterΦ9.550±0.007mm,Loading cylinder length:152± 0.100mmPiston head diameterΦ9.475±0.007mm,Piston head length:6.350±0.100mmStandard test loadA total of 8 full set of weightsTemperature control rangeRoom temperature~400ºC(Optional~400ºC)Room temperature ~500ºCTemperature control resolution0.1ºC0.1ºC0.1ºCConstant temperature accuracy0.5ºC0.5ºC0.2ºCDisplacement resolutionNone0.001mm0.001mmTemperature control 4h driftNo less than ±0.5ºCCartridge temperature recovery time after feeding≤4minClock range0~6000sClock resolution0.1-1sCountdown time settingFreely setAutomatic cutting deviceSet the interval time (any adjustable from 2 to 2000s) ,automatically complete the cuttingJog cutting deviceManual button electric cuttingManual cutting deviceManually rotating the handle to cutWeight load accuracy≤±0.5%Weight load range325-21600g discontinuous, combined load can meet standard requirementsMeasuring range0.1~100g/10minPower supplyAC220V / 50HZ or AC110 /600HZ; Choose different power supply voltagesNet weight48KGGross weight63KG
Packaging & Shipping

DH-MI-BP Touch Screen Melting Flow Index Test Equipment With Best Quality




Company Information

We, Dongguan Hongtuo Instrument Co., Ltd, a China based company, are pleased to introduce ourselves as a notable testing equipments and machines manufacturer.Our company was established in the year 2000 with two primarily motto, which includes complete client satisfaction and to reach top-most position in the international market. The exceptional quality of our products like Gold Tester,Gold Testing Machine,Density Meter,Universal Tensile Testing Machine,Climatic Chamber,Melt Flow Index Tester,Charpy Impact Testing Machine,Tap Density Tester,Abrasion Tester,Ultrasonic Flaw Detector,Surface Roughness Tester and other Laboratory Testing Equipment, etc. is our company's USP.


DH-MI-BP Touch Screen Melting Flow Index Test Equipment With Best Quality

Certification

DH-MI-BP Touch Screen Melting Flow Index Test Equipment With Best Quality


Related Products

Solids testing machine:DH-300,DH-600,DH-900,DA-300M,DA-600M,DA-900M,DA-1200M,DE-120M,DE-600M,DH-300M,DH-120M,DH-3000M,DH-120N
