• Model NO.：HD-B617-S
• Display：Digital
• Control：Computer Control
• Weight：500-1000Kg
• Power Source：AC220V
• Load Resolution：1,250, 000
• Load Accuracy：Within ± 0.5%
• Test Speed：0.1 to 500 mm,Min
• Stroke：1000mm
• Control and Display：Computer
• Capacity：5, 10, 50, 100, 200kg
• Unit：N, G, Kg, Kn, Lb
• Delivery Time：15 Days After Receive The Deposit
• Units：GF, Kgf, N, Lbf, W, Kn, T
• Transport Package：Strong Wooden Case
• Specification：ASTM D903 GB,T16491 GB,T1040 GB,T8808 GB13022 GB,T
• Trademark：Haida
• Origin：China
• HS Code：9024109000
• Production Capacity：150 Sets, Month

ItemDescriptionMax. Force500kg (5KN)Load cellGermany brand load cell for high accuracyControl systemLCD / PC with windows 7 systemMotorPanasonic servo motor w/ DC variable speed drive system, high-precision mechanical ball screw rodForce readingkgf, Ibf, N, KN, T etcStoke1400mm including fixtureLoad cell Resolution1/250,000Load Precisionwithin ±0.5%Test speed0.01~500mm/min (adjustable)SoftwareTM 2101Curves displayLoad- elongation, Elongation-time, Time-elongation, Stress-strainData displayMax. force, speed, sample information, strength(Kpa, Mpa, N/mm, N/mm2) etc…Safety featuresE-Stop
Over-load protection
Upper and lower limit switches
Load sensor with automatic retreat Main features:
1. It adopts windows format, the setting of parameter is in dialog box.
2. The software is with three languages: Simple Chinese, Traditional Chinese and English.
3. You can set the report format as you like; And you can choose to see the curve between time and Displacement, strength and displacement and time and strength.
4. It has several measuring units, and can be changed.
5. It has the function of automatic returning and calibration; Testing function Of sampling automatically and manually; Function of automatic magnifying to reach A graphic with suitable size.
6. The testing speed can be customized by requirements.
7. It has the functions of defining testing method automatically and calculating.
8. It can generate testing report automatically, and print out in A4 paper with curve or save in word format.



Packaging & Delivery

Packaging Details:
1. inner package: dust-proof plastic bag
2. outer package: standard export wooden case with pallet
3. suitable for international transport through shipping by sea, by air or any other delivery method.
(Note: we can provide special packages according to buyer's requirements.)
4. Packing size:
5. Gross weight:

The introduction of Haida
HAIDA INTERNATIONAL is a professional manufacturer of various kinds of testing equipments over 24 years. HAIDA products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and applicable to all scientific research units, quality inspection institutions and academic fields.
