• Model NO.：YCTL-408
• Temp. Fluctuation：+,-0.5degrees Under Room Pressure
• Temp. Uniformity：+,-2degrees Under Room Pressure
• Pressure Range：RP~0.5kpa
• Inner Chamber Material：304 Stainless Steel Plate
• External Chamber Material：Cold Rolled Plate+Powder Coating
• Insulation Material：PU Fiberglass Wool
• Cooling Way：Water Cooling
• Transport Package：Plywood Case
• Specification：CE, TUV, SGS Certificate
• Trademark：Yuanyao
• Origin：Guangdong, China
• HS Code：9032100000
• Production Capacity：100sets,Month

-60ºC~150ºCTemp.fluctuation±0.5ºC (RP)Temp.uniformity±2.0ºC (RP)Heating time3ºC/min (+20ºC~+150ºC,PR,empty load)Cooling time1ºC/minPressure rangeRP~0.5KPaPressure control error±0.2kPa(≤2kPa),±2(2kPa~40kPa),±5%(≥40kPa)Depressurization time≤45minExterior chamber materialCold rolled plate+Powder coatingInterior chamber materialSUS#304 stainless steel plateInsulation materialfiberglass woolAir cirulation systemCentrifugal fanHeating systemSUS#stainless steel high speed heaterCooling systemCompressor+condenser+evaporatorOther componentsSample shelves 2pcs,electronical wire 1pcs(3m),pressure test portSafety protection deviceOverheat protection circuit breakerCompressor overload protectionControl system overload protectionOverload indicator phase sequence protectionHigh voltage and low voltage protectionOver temperature protectionFan overcurrent protectionPower supplyAC 3ψ380V 60/50HzCustomization serviceNon-standard or special requirements are all welcome


About us:







Thanks a lot for your attention! Any questions, please feel free to contact us.
