• Model NO.：HTPV-08
• Control：Computer Control
• Weight：1000-2000Kg
• Power Source：AC220V
• Measurable Area Range：80*50cm-200*120cm(L*W) (Adjustable)
• Materils：Aluminum , Assembly by Rectangular Fittings
• Machine Standard：IEC 61215
• Size：260 X 180 X 200 Cm (L *W * D)
• Transport Package：Stronger Wooden Case
• Specification：IEC 61215
• Trademark：HOTOTECH
• Origin：Dongguan
• HS Code：9031809090
• Production Capacity：50 Sets Per Month

Basic Info.

Model NO. HTPV-08 Control Computer Control Weight 1000-2000Kg Power Source AC220V Measurable Area Range 80*50cm-200*120cm(L*W) (Adjustable) Materils Aluminum , Assembly by Rectangular Fittings Machine Standard IEC 61215 Size 260 X 180 X 200 Cm (L *W * D) Transport Package Stronger Wooden Case Specification IEC 61215 Trademark HOTOTECH Origin Dongguan HS Code 9031809090 Production Capacity 50 Sets Per Month

Product Description

IEC 61215 Mechanical Load Testing equipment

IEC61215 Mechanical Load Testing equipment standard
It's satisfy IEC61215 , IEC61646 standard

IEC61215 Mechanical Load Testing equipment purpose
This test is to determine the ability of the module to withstand wind , snow , static or ice loads


IEC61215 Mechanical Load Testing equipment specifications

1. Machine table exterior size:approx L 320 × D 180 × H 195 cm
2. Test positive Load the max 5400 Pa,reverse load the max 24 00 Pa
3. Aluminum extrusion structure,The platform and support are not deformed under stress state(Aluminum surface using electrophoretic coating process,Guaranteed not to change color)
4. The max test size 120 × 240cm
5. Calibrator:350 kg
6. Cylinder quantity:4 groups ,8 pieces
7. Cylinder outer diameter :80mm
8. Cylinder single group the max pressure > 6 bar
9. Cylinder single group the max out force > 300 kg
10. Cylinder Telescopic stroke:150 mm
11. sucker quantity: 8 groups , 32 pieces
12.  Sucker diameter:120 mm
13. The space of Between two sucker :120mm~ 400mm

Company introduction
  Dongguan Hong Tu Instrument Co.,ltd specializes in developing and producing PV module testing machines and established in 2006 year , we have firm connections and full cooperation form China's National Third-party Quality Inspection and Notarization Center on producing and developing high-precision tesitng machines

  We treasue the value of good quality , reasonable price and efficient serivce with cusotmer satisfaction , we expert ourselves in providing our cusotmers the best suitable testing designs and high quality testing machines to make you the utmost profit


Company Certificate
