Yarn Faults Classification Tester Yarn Fault Classifying System

Jinan Xinghua Instruments Co., Ltd.
  • After-sales Service：12 Month Excellent After Service
  • Warranty：1 Year
  • Max Diameter of Workpiece：Yarn Faults Classification Test
  • Type：Yarn Test Instruments
  • Maxcapacity：27 Grades
  • Display：Digital

Base Info

  • Model NO.：XHX-10
  • Control：Computer Control
  • Weight：100-500Kg
  • Power Source：AC220V
  • Transport Package：Plywood Case
  • Specification：4Tex-112 Tex
  • Trademark：XHINSTRUMENTS
  • Origin：China
  • HS Code：9024800000
  • Production Capacity：5000 PCS, Year

Description

Basic Info.

Model NO. XHX-10 Control Computer Control Weight 100-500Kg Power Source AC220V Transport Package Plywood Case Specification 4Tex-112 Tex Trademark XHINSTRUMENTS Origin China HS Code 9024800000 Production Capacity 5000 PCS/ Year

Product Description

Yarn Classimat is used as a testing instrument of checking harmful defects of yarn, which is suitable for common winder. It is mainly used in yarn quality detecting departments, it's a necessary measuring instrument for textile enterprises.

Feature

It detects and analyzes unusual yarn faults.

It classifies yarn faults (among them short-thick places 20 grades, long-thick places 3 grades, thin places 4 grades, totally 27 grades).

It can supply a fault frequency in 100km automatically by testing length.

It can appoint to cut yarn faults of some grades.

It has clearing yarn faults function according to channels process (neps, short-thick places, long-short places, long-thin places).It also can be used as yarn clearer in some cases.

Yarn count detecting (wrong count detecting).

It measures length and weight of winding yarn automatically.

It adjusts sensitivity and zero automatically.

It prints out various diagrams, reports and current screen contents.

It detects trouble, alarms and resumes trouble automatically.

It has expert system, which can make trade contrast and analysis, yarn faults trend analysis, and yarn faults distribution analysis of testing data.

Technical Parameter:

Measuring ModeCapacitive detecting
Suitable yarn varieties
 		cotton, wool, flax, silk, pure spinning of fiber and short fiber of blending
Suitable yarn count range4Tex-112 Tex (JYS-15C)
 8 Tex-200 Tex (JYS-20C)
 Note: It could be limited according to different counts range of fiber material
Suitable winding speed300m/min~1800m/min
Power Supply110V/220V, 50Hz/60Hz
Power consumption 300VA



Yarn Faults Classification Tester Yarn Fault Classifying SystemYarn Faults Classification Tester Yarn Fault Classifying System

1. How About Machines Calibration?
Answer: All machines is calibrated well in house before it is out of factory, XH Instruments  will provide you calibration report, if you need calibration certificate from third party, such as ISO 17025 certificate, we also can provide you with extra charge.
2. What about delivery way and delivery item?
Answer: Courier Express  Delivery, Sea  Delivery,  Air Delivery.
EXW Works, FOB, C&F, CIF, ClP, CPT, FCA, DDU.
3. How can I pay you?
Answer:Bank TT, Western Union, L/C, Paypal.
4. How about you after service?
Answer: XH Instruments will give a feedback within 24 hours.Warranty Period is 12 Months.
For problem caused by product quality within warranty period,XH Instruments will provide product maintenance, technical support, freight out and home as well as spare parts free of charge.
Problem not caused by product quality within warranty period or maintenance beyond warranty period is only charged for replaced parts. However, freight charges home and out are at customer' side (only the replaced part is charged if transportation of instrument is unnecessary).
