• Model NO.：TFG1903B,1905B,1910B,1920B
• Modulation：FM, Am, Pw, PWM, Fsk
• Sweep：Linear or Logarithmic
• Frequency Range：3MHz,5MHz,10MHz,20MHz
• Vertical Resolution：8bits
• Color：White and Blue
• Interface：USB Device
• Trigger Source：Internal,External,Manual
• Display：LCD
• Transport Package：Carton Package
• Specification：322*256*102 mm
• Trademark：SUIN
• Origin：China
• HS Code：8543209090
• Production Capacity：30, 000 Sets,Year

 TFG1903BTFG1905BTFG1910BTFG1920BFrequencyRangeSine10μHz ~ 3MHz10μHz ~ 5MHz10μHz ~ 10MHz10μHz ~ 20MHzSquare10μHz ~ 5MHzOthers10μHz ~ 1MHzResolution10μHzAccuracy±50ppmWaveformType16   waveform, Sine, Square, Ramp, Exp, Log, Noise, etc.Length1024 pointsSampling Rate100 MSa/sVertical Resolution8 bitsSineHarmonic Distortion≤-40dBc(≤5MHz);   ≤-35dBc(>5MHz)Total Distortion≤0.5% (20Hz ~ 20kHz, 20Vpp)   SquareRise/Fall Edge Time≤35ns        Overshoot: ≤ 10 %Duty Cycle0.1% ~ 99.9%RampSymmetry0.0% ~100.0%AmplitudeRangeFrequency≤8MHz0 ~ 10Vpp(50Ω),  0 ~ 20Vpp(Open circuit)Frequency>8MHz0 ~ 9Vpp  (50Ω),    0 ~ 18Vpp(Open circuit)Resolution 5mVpp(Amplitude>2Vpp)0.5mVpp(Amplitude≤2Vpp)DC Offset (Ampl.   0Vpp)Range±5Vdc (50Ω), ±10Vdc (Open   circuit)Resolution5mVdcModulationFM,AM,Carrier Waveform16   waveforms, Sine, Square, Ramp, etc. (only Pulse for PWM)PM,PWMModulating Waveform16 waveforms, Sine, Square,   Ramp, etc.Modulating Frequency40mHz ~ 20kHzFSKCarrier Waveform16 waveforms, Sine, Square,   Ramp, etc.Modulating WaveformSquareFSK Rate40mHz ~ 100kHzSweepTypeLinear or LogarithmicSweep SourceInternal/External/ManualSweep Time50ms ~ 500sBurstBurst Waveform16 waveforms, Sine, Square,   Ramp, etc.Burst Count1 ~ 1000000Internal Period1μs ~ 20sStart/Stop Phase0° ~ 360°Trigger SourceInternal/External/ManualSYNC OutputWaveform   CharacteristicSquare, edge time ≤ 20nsElectrical LevelTTL compatible Output Levellow level<0.3V,high level>4VGeneral   CharacteriscticsPowerAC 100 ~ 240V, 45 ~ 65Hz,   < 20VADisplayLCD displayDimension &   Weight322×256×102mm, Approx.1.5kg

Options:

Power Amplifier (output power:10W)
