• Model NO.：HTPV-17A
• Material：Stainless Steel
• Products Standard：IEC 61730: 2-2004
• Delivery：25 Work Days
• Packages：Stronger Wooden Case
• Transport Package：Wooden Case
• Specification：IEC 61730: 2-2004
• Trademark：HOTOTECH
• Origin：Dongguan
• HS Code：9013809000
• Production Capacity：50PCS

Basic Info.

Model NO. HTPV-17A Material Stainless Steel Products Standard IEC 61730: 2-2004 Delivery 25 Work Days Packages Stronger Wooden Case Transport Package Wooden Case Specification IEC 61730: 2-2004 Trademark HOTOTECH Origin Dongguan HS Code 9013809000 Production Capacity 50PCS

Product Description

PV module  Contactable Testing Machine

PV module Contactable Testing Machine Perform Standard:

It's according to IEC 61730: 2-2004

PV module Contactable Testing Machine Main function:

This sensor can be used to test the finger by mistake to contact dangerous parts Protection, also used to detect the strength of junction box open mechanical.

PV module Contactable Testing Machine Technical parameters:

Material: Metal, unless otherwise specified.

Size allows error: No special circumstances specified in the following:

The Angle: 0 ~-10 ° Center line size: Within 25 mm: 0 ~ 0.05 mm

25 mm above: + /-0.2 mm

Between joint shall be allowed to be in the same plane and the same direction Is conistent across the 90 ° Angle (0 ~ 10 ° Error) activities.

The probe specializing used to detect specially dangerous part of the basic Protection contact, the test means also be used to detect security protection.

Number 11 cylindrical test applied pressure: 50 N

Model	HTPV-17A
Material	Metal , unless otherwise specified
Function	use to test the finger by mistake to contact dangerous parts protection  and detect the strenght of junction box open mechanical

Testing Machine Package
