Dgbell Laptop Battery Free Fall Drop Test Equipment
GUANGDONG BELL EXPERIMENT EQUIPMENT CO., LTD.- After-sales Service：Support
- Warranty：1 Year
- Mass Scope of Workpiece：<900kg
- Type：Drop Testing Machine
- Loading Method：Dynamic Load
- Display：Digital
Base Info
- Model NO.：BE-8108
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Product Name：Battery Dropping Test Machine
- Testing Method：Free Fall
- Test Loading：0~5kg
- Specimen Max. Dimension：W200 X D200 X H200mm
- Machine Dimension：W700 X D900 X H1800mm
- Motor Power：90W
- Internal Material：SUS 304# Stainless Steel
- External Material：1.5mm Thickness Cold Plate
- Falling Method：Pneumatic Drop
- Lifting Method：Electric
- Power Supply：220V 50Hz
- Safety Device：Fully Enclosed Explosion-Proof Device
- Transport Package：Each Set Protected with Resin Fiber and PP Film, T
- Specification：Test Space200x200x200(customizable)
- Trademark：DGBELL
- Origin：Guangdong China
- HS Code：9031809090
- Production Capacity：100set ,Month
Description
| Model | BE-8108 |
|---|---|
| Drop Height | 300~1500mm (Adjustable) |
| Testing Method | Free fall |
| Test Loading | 0~5kg |
| Specimen Max. Dimension | W200 x D200 x H200mm |
| Machine Dimension | W700 X D900 X H1800mm |
| Motor Power | 90W |
| Control Mode | PLC touch screen (7-inch touch screen) + Remote control |
| Internal Material | SUS 304# Stainless steel |
| External Material | 1.5mm thickness Cold plate |
| Falling Method | Pneumatic drop |
| Lifting Method | Electric |
| Power Supply | 220V 50Hz |
| Safety device | Fully enclosed explosion-proof device |
| Pressure | >0.3Mpa |
| Drop Panel Size | W600 x D700 x H10mm (solid steel), hardwood, cement board (optional) |
| Observation Window | 390 X 360mm (20mm thickness tempered explosion-proof glass) |
| Data Output | Test data can be output by USB flash disk directly . |
| Safety Protection | Explosion-proof pressure relief device, smoke exhaust device, fire extinguishing system, electronic door lock system, safety stop switch |
| Options | Temperature acquisition system, voltage acquisition system, video monitoring system |
Established in 2005, Guangdong Bell Experiment Equipment Co., Ltd is specialized in manufacturing a variety of quality inspection instruments, testing equipments and other high-tech products which mainly include: Constant Temperature & Humidity Test Chamber,High & Low Temperature Test Chamber, High & low Temperature Testers with Rapid Temperature Change, Walk-In humidity & temperature test chamber, Cool/Thermal shock test chamber, Salt spray chamber, High temperature aging tester, sand and dust testing machine,tension tester, high and low temperature testing machine , servo computer battery crush tester, mechanical vibration testerBattery washing tester ,battery burning tester and other quality testing instruments. Thanks to several decades of R&D efforts,the company has established itself as a leading provider of testing instruments of the industry, playing a crucial role in the research and development of high-quality and high-value products within the industry.
15+ years experience in test chambers manufacturing, High performance for your projects.
With unmatched quality advantage, a dynamic management team, professional customer services, superb manufacturing techniques and innovative research and development ideas, Guangdong Bell Experiment Equipment Co., Ltd, supported by an international, standard and professional quality policy, is gradually becoming an international brand. Its products are manufactured in consistent with a number of world standards.
FAQQ1 : Can you customize the product?
A: Yes, we can customize any products according to requirements. Hot selling lab electronic
temperature humidity cabinet/Environmental climate test chamber/Car Battery Safety Test Chamber also can be customized.
Q2 : How to choose the most suitable products?
A: Our professional team will give you the best suggestion, just be patiently to tell us the information
about the parameters you require.
Q3 : Can you arrange installations and commissioning in our lab?
A: Firstly, for standard chamber we had 3-5 days commissioning before shipping,
you just need link power in your lab, then you can start to operate.
Secondly, we had detailed operation manual with chamber , any problems you can find and solve in it.
Thirdly, some customized chambers we should install and teach your team to operate .
