Insulation Resistance Tester Meter Megohmmeter
Sansion Power Electric Co., Ltd.- Control：Manual Control
- Weight：0-100Kg
- Power Source：AC220V
- Charging Source：AC220V 50 Hz (±10 %)
- Power Supply：14.8V(2.2ah)Chargeable Lithium Battery.
- Voltage Withstand: ：AC2.5kv 50Hz 1min
Base Info
- Transport Package：Plywood Case
- Specification：ISO9001 SGS
- Trademark：Sansion
- Origin：Wuhan China
- HS Code：9030339000
- Production Capacity：100 Units
Description
Rated Voltage(V)
500
1000
2500
5000
Working Voltage(V)
Rated Voltage×(1±10%)
Measuring Range
0~100GΩ
0~200GΩ
0.001~500GΩ
0.001~1000GΩ
Max. Error:±10%RDG+1d (The max. displayable measuring value is1999)
Output Short Circuit Current
≥1.5mA
≥1.5mA
≥5mA
≥5mA
Absorption Ratio, Polarizability Index
Measuring Range: 0.1~19.99. Max. Error: ±2% RDG+1d
√ Power Consumption: ≤10W
√ Working Temperature and Humidity: 0ºC~40ºC; ≤ 85 % RH
√ Voltage Withstand: AC2.5kV 50Hz 1min
√ Power Supply: 14.8V(2.2Ah)Chargeable Lithium Battery.
√ Charging Source: AC220V 50 HZ (±10 %)
√ Voltage range is customized.
More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
