GD-2133 Underground Cable Fault Detector

HV Hipot Electric Co., Ltd.
  • Type：Universal Testing Machine
  • Accuracy Grade：1m
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control

Base Info

  • Model NO.：GD-2133
  • Weight：1.8kg
  • Power Source：AC220V
  • Max. test distance：15km
  • Blind detection：1m
  • Resolution：1m
  • Power consumption：5VA
  • Atmospheric pressure：86-106Kpa
  • Size：275*220*160mm
  • Transport Package：Standard Export Wooden Box
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan, China
  • HS Code：9030899090
  • Production Capacity：5000set,Year

Description

Basic Info.

Model NO. GD-2133 Weight 1.8kg Power Source AC220V Max. test distance 15km Blind detection 1m Resolution 1m Power consumption 5VA Atmospheric pressure 86-106Kpa Size 275*220*160mm Transport Package Standard Export Wooden Box Specification ISO, SGS Trademark HV Hipot Origin Wuhan, China HS Code 9030899090 Production Capacity 5000set/Year

Product Description

GD-2133 Underground Cable Fault Detector

It can test faults of short circuit, grounding, high impedance leakage, high impedance flashover fault and cable's poor connection, disconnection for all kinds of power cables (voltage degree 1kV-35kV) , local cable, communication cable, coaxial-cable and metal overhead line. It also can measure cable's length and propagation speed of electric wave speed on the cable.

Features
  1. Safe, prompt and accurate testing. It uses LV impulse method and HV flashover detection, which test all kinds of cable faults.
  2. Using high speed data sampling technology. A/D sampling speed is 100Mhz.
  3. Wave form and data automatically display on big LCD screen.
  4. Wave form and parameter storage function.
  5. Function of comparing testing waveform of cable fault with normal waveform.
  6. Wave form extending function.
  7. Directly show fault point and testing point direct distance or relative distance.
  8. Modify speed of propagation any time according to different testing cables.
  9. Built-in rechargeable battery. Small size, portable to carry.

Specifications

  1. Max. test distance: 15km (Open wire up to 100km) according to customer's requirements.
  2. Blind detection: 1m
  3. Resolution: 1m
  4. Power consumption: 5VA
  5. Environmental temperature: 0-40ºC(limit temperature:-10ºC-50ºC)
  6. Relative humidity: 40ºC(20~90)%RH
  7. Atmospheric pressure: 86-106Kpa
  8. Size: 275*220*160mm
  9. Weight: 1.8kg
