Stainless Steel Ultra Thin Wall Hypodermic Needle Stiffness Bending Deflection Tester
Pubtester Instruments Co., Ltd.- Deflection Range：0-5mm
- Deflection Accuracy：0.01mm
- Setting Load：1-80n
- Force Accuracy：0.01n
- Needle Bracket Distance：0-60mm
- Distance Accuracy：0.1mm
Base Info
- Model NO.：MRT-01
- Loading Speed：0-10mm,Min (Stepless Speed)
- Test Item：Needle Tubing Stiffness
- Trademark：Pubtester
- Origin：Jinan, Shandong
- Production Capacity：30 Sets,Quarter
Description
Extended ApplicationsInfusion needle Used to detect the rigidity value of the infusion needle tube Needle tube Determination of rigidity values such as stainless steel needles, blood sampling needles, dental needles and biopsy needles
Technical Specifications
Standards
GB 15811, YBB00092004-2015, GB 18457
Configuration
Standard configuration: Instrument, micro printer, touch screen, test fixture.
FAQ
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
Technical Specifications
| Specifications | MRT-01 |
| Deflection Range | 0-5mm |
| Deflection Accuracy | ±0.01mm |
| Setting Load | 1-80N |
| Force Accuracy | ±0.01N |
| Needle Bracket Distance | 0-60mm |
| Distance Accuracy | 0.1mm |
| Needle Tube Specifications | 0.3mm-3.4mm (Normal wall, thin wall, ultrathin wall) |
| Loading Speed | 0-10mm/min (Stepless speed) |
| Speed Accuracy | ±0.1mm/min |
| Instrument Dimension | 300mm (L) x 300mm (W) x 400mm(H) |
| Net Weight | 23Kg |
| Power Supply | 220V/50Hz |
Standards
GB 15811, YBB00092004-2015, GB 18457
Configuration
Standard configuration: Instrument, micro printer, touch screen, test fixture.
