• Model NO.：XHXC205
• Certification：CE
• Customized：Customized
• Trademark：XZH TEST
• Origin：China Xi′an
• HS Code：854320100
• Production Capacity：1000 Pieces ,Year

Basic Info.

Model NO. XHXC205 Certification CE Customized Customized Trademark XZH TEST Origin China Xi′an HS Code 854320100 Production Capacity 1000 Pieces /Year

Product Description

XHXC205 Power transformer degaussing machine

Description
XHXC205 is a combination of power transformer degaussing instrument and power transformer DC resistance tester, which has conventional transformer DC resistance test function.

Main features
Degaussing part
Adopt patented technology - DC frequency conversion attenuation principle;
The three-phase transformer can only achieve degaussing by degaussing the B phase;
With automatic steady flow judgment, 16-bit AD data acquisition and processing functions;
With manual / automatic degaussing mode, total 5 degaussing modes;
Degaussing speed is fast: single time is increased from 30min to less than 4min;
The degaussing effect is obvious: from 80% up to over 90% in a single time;
The current line of the DC resistance test can be directly used to facilitate the matching with the DC resistance test;
Adopt Chinese/English user interface, the user interface is clear, and the degaussing progress is displayed in real time;
9. It is suitable for eliminating residual magnetism before large power transformers of 35kV and above; especially for large-capacity transformers with voltage levels of 330kV and above;
DC resistance test part
The test range is 200.0uΩ to 50kΩ wide;
The test process is controlled by a microcomputer, and self-calibration, steady flow judgment, data processing, and resistance display are automatically completed;
Has a perfect back EMF protection function;
The longitudinal test of the DC resistance of the on-load tap changer can be completed at one time;
200 sets of test data can be stored permanently.
The measuring speed is fast and the measurement data is accurate and stable;
The machine is small in size and light in weight, and has the characteristics of simple operation, high precision, anti-interference, shockproof and portable.

Main Technical Parameters
Degaussing part
Degaussing current: 5A, 1A, 200mA, 5mA (can customized)
Degaussing mode: manual, automatic
Degaussing time: manual: 4min/time;  automatic: 11min/time
Degaussing effect: >90% / time
Degaussing progress: 0~100%
Working power supply: AC 220V ± 10%
Power frequency: 50Hz ± 1Hz
Ambient temperature: -25°C ~ 50°C
Ambient humidity: ≤90%
Weight: 5kg (excluding test line)
DC resistance test part
Steady current: 20A, 10A, 5A, 1A, 100mA, 10mA, 1mA
Test range: 1mA: 500Ω~50kΩ
     10mA: 20Ω~2kΩ
     100mA: 1Ω ~ 200Ω
     1A: 100mΩ to 20Ω
     5A: 2mΩ to 4Ω
     10A: 500μΩ ~ 2Ω
     20A: 200μΩ ~ 1Ω
Resolution: 0.1μΩ
Accuracy: ± (0.2% reading + 2 words)
