• Model NO.：55-C0193,A
• HS Code：90248000
• Production Capacity：200 Sets,Month

Basic Info.

Model NO. 55-C0193/A HS Code 90248000 Production Capacity 200 Sets/Month

Product Description

55-C0193/A Plastic Concrete Specimen Curing Tank

Both ASTM and EN specifi cations require the specimens to be left in the mould for the fi rst 16 hours up to a maximum of three days, protected against shock, vibration and dehydration at a temperature from 20 ± 5°C or 25 ± 5°C in hot climates (EN method) and 16 to 27°C (ASTM method).
After the removal from the moulds the specimens have to be stored in a moist condition at 20 ± 2°C (EN) or 23 ± 1.7°C (ASTM) with a relative humidity ≥ 95%. Alternatively they can be cured in water at the same temperature.

Model 55-C0193/A plastic curing tank is designed for curing concrete cubes and cylinders.



Temperature range: from ambient to +40°C
Wattage: 3000 W
Capacity: 165 litres
Overall dimensions: 870x570x370 mm
Weight approx.: 10 kg
