• Model NO.：HD-D114
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V
• Usage：Suitcase Leather Case Oscillation Impact Tester
• Impact Height：4 Inch (0~6 Inches)Adjustable
• Oscillation Mode：Spring Type: 1.79kg,mm
• Testing Speed：5~30 C.P.M. Adjustable
• Times Setting：1~999999 Automatic Shutdown
• Additional Fucnction：Would Stop Automatically If Something Goes Wrong.
• Dimension：1400*1200*2500 mm
• Power：220V,50Hz
• Design Criteria：Qb,T2922-2007
• Modle：HD-D114
• Transport Package：Strong Wooden Case
• Specification：ISO9001-2008
• Trademark：Haida
• Origin：China (Mainland)
• HS Code：9024109000
• Production Capacity：70PCS,Month

Basic Info.

Model NO. HD-D114 Control Computer Control Weight 100-500Kg Power Source AC220V Usage Suitcase Leather Case Oscillation Impact Tester Impact Height 4 Inch (0~6 Inches)Adjustable Oscillation Mode Spring Type: 1.79kg/mm Testing Speed 5~30 C.P.M. Adjustable Times Setting 1~999999 Automatic Shutdown Additional Fucnction Would Stop Automatically If Something Goes Wrong. Dimension 1400*1200*2500 mm Power 220V/50Hz Design Criteria Qb/T2922-2007 Modle HD-D114 Transport Package Strong Wooden Case Specification ISO9001-2008 Trademark Haida Origin China (Mainland) HS Code 9024109000 Production Capacity 70PCS/Month

Product Description

Automatic Baggage Oscillation Impact Test Instrument

Description:
Suitcase Leather Case Oscillation Impact Test Machine is applicable to testing the resistance of oscillating impact of the handle, sew stitch lines and the whole structure of luggages. The testing methods are as follows: First, Load the object with stated load weight. And then do the test to the specimen with the speed of 30 times per minute and the impact height of 4 inches for 2500 times. The tset result can be taken into consideration of quality improvement.

Main Parameters:

Model	HD-D114
Impact Height	4 inch (0~6 inches)adjustable
Oscillation Mode	Spring type: 1.79Kg/mm
Testing Speed	5~30 C.P.M. adjustable
Times Setting	1~999999   Automatic shutdown
Additional Fucnction	It would stop automatically if something goes wrong.
Dimension	1400×1200×2500 mm
Weight	390 Kg
Power	220V/50Hz
Design criteria	QB/T2922-2007

(The table parameters for the company Standard Model parameters, we support customer customization parameters)



After-service:
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-con.

Why choose us?
1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.
2. Excellent After sale Service:
18 months warranty. Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.
3. Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.
4. Good Packaging:
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
