• Model NO.：GW-399
• Control：Manual Control
• Weight：100-500Kg
• Power Source：AC220V
• Packaging：Wooden Case
• Export Markets：Global
• Model No：Gw-388b
• Metal Table Size (mm)：510*290
• Power：AC 220V,50Hz
• Travel Mileage (mm)：500*400*300
• Camera: Color 1 / 3 " CCD Camera ：Color 1 , 3 " CCD Camera
• Transport Package：Wooden Case
• Specification：510*290(mm)
• Trademark：Great Win
• Origin：China
• Production Capacity：500 Pieces,Year

Basic Info.

Model NO. GW-399 Control Manual Control Weight 100-500Kg Power Source AC220V Packaging Wooden Case Export Markets Global Model No Gw-388b Metal Table Size (mm) 510*290 Power AC 220V,50Hz Travel Mileage (mm) 500*400*300 Camera: Color 1 / 3 " CCD Camera  Color 1 / 3 " CCD Camera Transport Package Wooden Case Specification 510*290(mm) Trademark Great Win Origin China Production Capacity 500 Pieces/Year

Product Description

Automatic Three Coordinate Measuring Instrument (GW-399)

Applicable industry:
Precision Rubber Plastic: Length, width, height, thickness, curvature, distance, anteroposterior degree, color analysis, crude analysis2. Precision Mould: Length, width, height, thickness, curvature, distance, anteroposterior degree3. PCB: Thickness, diameter and area of orthotopic degree tin point, line width, V-Cut, Lay out, cheat, surface defects observed4. Mask stencil size inspection, surface defect observation5. Leadframe package size of semiconductor inspection, surface defect observation, photography6. Metal stamping parts: Length, width, height, thickness, curvature, distance, anteroposterior, rough analysis, observation of surface defects7. Automobile parts, communication parts, mobile phone parts, 3C parts, Connecter size parts such as inspection, observation of surface defects8. Aluminum alloy casting, precision metal chassis, thermal materials, such as laptop size measurement.

Technical parameter:
U Model: Hz-3504D
U table: 1) Full aluminum structure or yellow granite base, all-stroke measurement is not vacant bed. Holes with screws. The best level of glass adjustable support platform. Glass with a fixed rule, fixed and compacted soft parts (optional). 2) load capacity: 50lbs 3) X Y Z axis servo motor drive with DC 4) XYZ axis with linear scale (resolution 1um/0.5um/0.1um) 5) X Y Z axis speed: 100mm / S 6) linear slide. Precision ball bearing drive 7) Measuring range X: 200mm (300mm) Y: 150mm (300mm) Z: 150mm

U Camera:
1) black and white and color
2) 768 × 494PIXEL ARRAY
3) Automatic contrast black and white or color
U Optical System:
U 1) 6000Zoom Lens System automatically zoom magnification;
2) 20X magnification to 125 × ;
3) double lens 40X to 250 × ;
4) 12 × Zoom Lens System automatically zoom magnification;
5) 14X magnification to 167 × ;
6) double lens 28 × To 335 × .
Technical Specifications:

Model	CNC654	CNC754	CNC854	CNC866	CNC1066	CNC1086	CNC1286
Measuring Range(mm)	X 500 Y 600 Z 400	X 500 Y 700 Z 400	X 500 Y 800 Z 400	X 600 Y 800 Z 600	X 600 Y 1000 Z 600	X 800 Y 1000 Z 600	X 800 Y 1200 Z 600
Overall Dimensions(mm)	X 1250 Y 1500 Z 2500	X 1250 Y 1600 Z 2500	X 1250 Y 1700 Z 2500	X 1350 Y 1750 Z 2900	X 1350 Y 1950 Z 2900	X 1550 Y 1950 Z 2900	X 1500 Y 2150 Z 2900
Resolution(um)	0.5	0.5	0.5	0.5	0.5	0.5	0.5
E(um,L:mm)per ISO10360-2 Maximum Permissible Erro	2.7+L/250	2.7+L/250	2.7+L/250	2.8+L/250	2.8+L/250	2.9+L/200	3.0+L/200
Max.Velocity(mm/s)	300	300	300	300	300	300	300
Air Requirements(kg/cm²,NL/min)	0.6~0.8Mpa	0.6~0.8Mpa	0.6~0.8Mpa	0.6~0.8Mpa	0.6~0.8Mpa	0.6~0.8Mpa	0.6~0.8Mpa
Max.Workpiece Weight(kg)	500	500	500	800	800	1000	1000
Machine Weight(kg)	650	700	750	1300	1300	1700	1900

What about the product quality?
For our products, each instrument must be carried out 100% quality calibration and test when delivery goods. With CE certificate, we are very confident in our products, and we will pack them with safety wooden case to protect the machine when transport oversea.

What about usage of the machine?
We will also give your professional guidance(Product operating manual and video), each products comes with a USB flash drive which have all the details.

What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support, we can help them solve their problem through email, video meeting. We also can provide door to door service, but customer need to bear the travel fees.

What about standards support?
We are strictly following different international standards such as EN, ISO, ASTM, AATC, JIS, GB ect, and had been recognized by SATRA, CSA international standard agency.
