• Model NO.：GD-R1072
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Na
• Item Name：Petroleum Product Cloud Point, Pour Point Tester
• Application：Determine Pour Point, Cloud Point of Petroleum Oil
• Function：Check Low Temp. Quality of Oil
• Reference Standard：ASTM D97, ISO301
• Temperature Control Range：Room Temperature to -40c
• Cooling Method：Double Compressor Cooling
• Timing Method：Digital Timer
• Sample Quantity：2PCS
• Power Supply：220V 50Hz
• Warranty：1 Year
• Transport Package：Venner Case
• Specification：90*60*99CM
• Trademark：GOLD
• Origin：Chongqing, China
• HS Code：9031809090
• Production Capacity：100 Set,Month

Basic Info.

Model NO. GD-R1072 Loading Method Static Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Na Item Name Petroleum Product Cloud Point, Pour Point Tester Application Determine Pour Point, Cloud Point of Petroleum Oil Function Check Low Temp. Quality of Oil Reference Standard ASTM D97, ISO301 Temperature Control Range Room Temperature to -40c Cooling Method Double Compressor Cooling Timing Method Digital Timer Sample Quantity 2PCS Power Supply 220V 50Hz Warranty 1 Year Transport Package Venner Case Specification 90*60*99CM Trademark GOLD Origin Chongqing, China HS Code 9031809090 Production Capacity 100 Set/Month

Product Description

GD-R1072 ASTM D97, ISO3016 Petroleum Products Cloud Point and Pour Point Test Apparatus

Introduction:

1. GD-R1072 ASTM D97, ISO3016 Petroleum Products Cloud Point and Pour Point Test Apparatus is designed and made refer to GB/T3535  ASTM D97  ISO3016  NFT60105
2. GD-R1072 ASTM D97, ISO3016 Petroleum Products Cloud Point and Pour Point Test Apparatus is suitable to determine pour point of petroleum oils.

Specifications:

Item Name	GD-R1072 ASTM D97, ISO3016 Petroleum Products Cloud Point and Pour Point Test Apparatus
Temperature control range	Room temperature to -40ºC
Temperature control accuracy	0.1°C
Temperature detector	Pt100 RTD temperature detector
Temperature control method	PID digital temperature controller
Cooling method	Double compressor cooling
Timing method	Digital timer
Total power	400W
Sample quantity	2 pcs

Features:

1. It adopts two sets fully enclosed compressor for cooling and environmental protection refrigerant, which make the cooling very fast;
2. It adopts Taiwan made self-priming pump for cycling, which make the instrument with good temperature uniformity;
3. Integral structure which is convenient to move;
4. Made with cold-rolled steel material, the surface with electrostatic spray treatment, so the instrument is corrosion-resistant and easy to clean;
5. Micro-computer control, PID function, temperature digital display;
