Affordable Price Wholesale Hdt Vicat and Heat Deflection Tester Machine for Plastics

Jinan Xinghua Instruments Co., Ltd.
  • After-sales Service：12 Month Excellent After Service
  • Warranty：1 Year
  • Max Diameter of Workpiece：GB,T 1633, GB,T 8802, GB,T 1634, ISO 2507-1-2-3, I
  • Type：Hdt and Vicat Test
  • Maxcapacity：300c
  • Accuracy Grade：0.5c

Base Info

  • Model NO.：XHS-15
  • Loading Method：Static Load
  • Display：Digital
  • Control：Computer Control
  • Weight：100-500Kg
  • Power Source：AC220V
  • Transport Package：Plywood Case
  • Specification：Plastic Test
  • Trademark：XHINSTRUMENTS
  • Origin：China
  • HS Code：9024800000
  • Production Capacity：5000 PCS, Year

Description

Temperature Control Range

Room Temperature-300C

Max Temperature Error

±0.5C

Heating Rate

50C/h, 120C/h

Test Station

3

Deformation Measurement Method

High Precision Dial Gauge

Deformation Measurement Range

0-10mm

Max Deformation Error

±0.005mm

Resolution of Deformation

0.001mm

Sample Span

64mm, 100mm

Thermal Expansion Coefficient of Sample Frame

<0.005/100ºC (important)

Sample Frame

Auto up and down

Heating Medium

Methyl silicon oil

Cooling Method

Natural Cooling or water cooling below 150C, Natural Cooling Above 150C

Dimension

950mmX660mm*1200mm

Weight

160Kgs

Power Supply

220V, 50Hz/60Hz, Single Phrase


Affordable Price Wholesale Hdt Vicat and Heat Deflection Tester Machine for PlasticsAffordable Price Wholesale Hdt Vicat and Heat Deflection Tester Machine for Plastics
1. How About Machines Calibration?
Answer: All machines is calibrated well in house before it is out of factory, XH Instruments  will provide you calibration report, if you need calibration certificate from third party, such as ISO 17025 certificate, we also can provide you with extra charge.
2. What about delivery way and delivery item?
Answer: Courier Express  Delivery, Sea  Delivery,  Air Delivery.
EXW Works, FOB, C&F, CIF, ClP, CPT, FCA, DDU.
3. How can I pay you?
Answer:Bank TT, Western Union, L/C, Paypal.
4. How about you after service?
Answer: XH Instruments will give a feedback within 24 hours.Warranty Period is 12 Months.
For problem caused by product quality within warranty period,XH Instruments will provide product maintenance, technical support, freight out and home as well as spare parts free of charge.
Problem not caused by product quality within warranty period or maintenance beyond warranty period is only charged for replaced parts. However, freight charges home and out are at customer' side (only the replaced part is charged if transportation of instrument is unnecessary).
