• Model NO.：GDYJ-502
• Display：256´128 LCD
• Maximum Storage Capacity：100 Groups of Test Data
• Power Supply：AC220V±10%, 50Hz,60Hz
• Transport Package：Plywood Case
• Specification：55kg
• Trademark：GOLD
• Origin：Chongqing, China
• HS Code：9030849000
• Production Capacity：200piece,Month

620 mm*430mm*330mm

Weight

Functions:

• Breakdown test of user-defined;

• Proof test;

• IEC60156/IS6792/BS5874 test;

• ASTM D1816 standard test;

• ASTM D877 standard test;

• 5 minutes standard test;

• Manual test;

• Calibration interface for customers;

• Uploading data to PC and making word report automatically;

• Result print;

Features:

• LCD screen can display test procedure and test result;

• All the human interaction operations complete by the rotating mouse;

• It is very easy for customers to measure the breakdown voltage of all kinds of oil;

• You can print the test result by the micro printer internal the tester;

• Meanwhile, you can upload the test data to PC from RS232 for data analyzing;

• The special circuit design makes the tester has a good performance at stability and anti-noise;


  Testing Process
