ASTM F1921 Hot Seal Strength Stripping Tester Manufacturer
Pubtester Instruments Co., Ltd.- Sealing Temperature：Room Temperature ~ 300 Degree
- Temperature Accuracy：0.2 Degree
- Dwell Time (Heat Seal Test)：0.1~ 999.9s
- Temperature Uniformity：1 Degree
- Dwell Time (Hot Tack Test)：0.1~ 999.9s
- Sealing Pressure：0.05 MPa ~ 0.7 MPa
Base Info
- Model NO.：HTT-01
- Sealing Area：100 mm ×5mm
- Transport Package：Veneer Case
- Trademark：Pubtester
- Origin：Jinan, Shandong
- Production Capacity：30 Sets,Quarter
Description
Extended ApplicationMedical Adhesives Peeling test and tensile strength test of medical adhesives e.g. adhesive bandages Adhesive Tapes Low speed unwrapping test Textiles, Nonwovens and Woven Bags Peeling test and tensile strength test Protection Films Peeling test and tensile strength test Magnetic Cards Peeling test of the films and magnetic cards Bottle Caps Opening force test of the aluminum plastic combination bottle caps
Standards
ASTM F1921, ASTM F2029, QB/T 2358, YBB 00122003
Configuration
Standard configuration: Instrument, 7-inch touch screen, Pedal Switch, Hot tack Clamp, Calibration bracket
Optional configuration: Professional software, communication cable, non-standard sealing jaw, testing board, welding cloth, non-standard fixture, sampler, non-standard sample positioning board.
Note: 1. Φ4 mm PU port for gas supply port;
2.Customer need to prepare gas.
FAQ
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
| Specifications | HTT-01 |
| Sealing Temperature | Room temperature ~ 300 °C |
| Temperature Accuracy | ±0.2 °C |
| Dwell Time (Heat Seal Test) | 0.1~ 999.9s |
| Temperature Uniformity | ± 1 °C |
| Dwell Time (Hot Tack Test) | 0.1~ 999.9s |
| Sealing Pressure | 0.05 MPa ~ 0.7 MPa |
| Sealing Area | 100 mm ×5mm |
| Heating Mode | Single or Double Heating Surfaces (Customization) |
| Gas Supply Pressure | 0.5MPa~0.7MPa (Not in Supply Scope) |
| Port Size | Φ4mm PU Tubing |
| Load Cell Capacity | 0~200 N ( 30N, 50N, 100N, 500N optional ) |
| Force Accuracy | 0.5% FS |
| Force Resolution | 0.001N |
| Test Speed | 0.05 ~ 3000 mm/min |
| Specimen Width | 15 mm, 25 mm or 25.4 mm (Customization) |
| Stroke | 500 mm |
| Instrument Dimension | 1170mm (L) × 360 mm (W) × 460 mm (H) |
| Power Supply | AC 220V 50Hz / AC 120V 60HZ |
| Net weight | 45 kg |
