3000A Primary Current Injection Test Set

HV Hipot Electric Co., Ltd.

Power Supply：AC380V±10%
Frequency：50Hz ± 1
Output current：3000A
Output Capacity：18kVA
Output voltage：6V
Operating time：3000A,2-3minutes; 1500A,3-6minutes

Base Info

Model NO.：GDSL-D-3000
Ambient temperature：-20 ºC to 50 ºC
Current accuracy：≤ 1.5% (F.S)
Transport Package：Wooden Case
Specification：ISO, SGS
Trademark：HV Hipot
Origin：Wuhan, China
HS Code：9030899090
Production Capacity：2000PCS,Year

Description

Output current0-3000A ACOutput Voltage6VCapacity18kVAInput voltageAC400V, Single phase, 50HzInput current45AOperating time3000A/2-3minutes; 1500A/3-6minutesAmbient temperature-20 ºC to 50 ºCCurrent accuracy≤ 1.5% (F.S)

Contact Information
HV Hipot Electric Co.,Ltd.F/10, Block 7, Area B, JinYinTan Modern Enterprise City, Dongxihu District, Wuhan, 430040,China.
Website: hv-hipot.en.made-in-china.com

3000A Primary Current Injection Test Set

3000A Primary Current Injection Test Set

3000A Primary Current Injection Test Set
