• Model NO.：PN-ST500
• Specification：ISO
• Trademark：PNSHAR
• Origin：Hangzhou, Zhejiang
• HS Code：90248000
• Production Capacity：300sets,Year

NO.ITEMSPECIFICATION1Power Supply: AC(100~240)V 2A 50/60Hz2Indication Error: +/-1%3Indication Offset: less than 1%4Measure Range: (20 ~ 10000)mN Eqv (1 ~ 500) mN.m5Resolution: 0.1mN6Bend Length: (50+/-0.5)mm/(25+/-0.5)mm/(10+/-0.5)mm7Bend angle:(1~20);8Display: 4.3" Color touch screen9Printer: Thermal Printer10Output: RS232(Standard) / USB(optional)11Dimension: (320*300 *300)mm(L*W*H)12Weight: 16kg5. FEATURES:
1). Bending angle: Standard measurement 7.5 degree and 15degree; (from 1 degree to 20degree can be set).
2). Test time: From 3s to 30s you can set.
3). Bending lengths: Three kinds of length you can be selected.
4). With auto zero function, before test you needn't align the sample.
5). Measurable statistics, print and other functions, measuring time can be set.
6). Once test is over, quickly return to start position, returning velocity you can set from 1 degree/s o to 12 degree/s freely.
7). Color touch screen, dual-language operating system.
8). Real-time display the measurement results.
