Test Instrument

Leak Tester and Seal Strength Detector for Finished Packages and Three-Side Sealed Packaging

Pubtester Instruments Co., Ltd.
  • Standard:ASTM F2054, ASTM F1140
  • Test Sample:Sealed Plastic Pouches
  • Test Item:Destructive, Leak Test
  • Test Range:0 ~ 600kpa;0~87psi
  • Trademark:Pubtester
  • Origin:Jinan, Shandong

Base Info

  • Model NO.:LSST-01
  • Production Capacity:10 Sets,Quarter

Description

Extended ApplicationHigh-pressure TestThe maximum pressure applied can be 1.6MPaPilfer-proof ClosureSeal performance tests of various pilfer-proof closuresThree-sided Sealing MaterialsTests of packaging bags with three-sided seal and one-sided openCompression resistance of medical blister packTests of various blister packsSoft TubesTests of various soft tubes for daily chemical products including toothpaste, facial cleaner, cosmetics as well as medical creams and some food productsAerosol ValvesTests of various aerosol valves, e.g. vales of pesticide, hair spray, auto spray paint and medical spray packages
Technical SpecificationsTest Range0 ~ 600kPa;0~87psi (Standard)0 ~1.6 Map;0 ~232.1 psi (Optional)Gas Injection HeadΦ10 mm (Standard) Φ4 mm, Φ1.6 mm (Optional)Gas Supply Pressure 0.4 Map~0.7 Map (Not in supply scope)Port SizeΦ8 mm PU TubingNo. of Load Cell1Instrument Dimension310mm(L)×370mm(W)×150mm(H)Pedestal Size305mm(L)×356mm(W)×325mm(H)Power SupplyAC 220V 50Hz/ AC 110V 60HzNet Weight25Kg
Standards

ASTM F2054, ASTM F1140, ISO 11607-1, ISO 11607-2, GB 18454, GB 19741, GB 10440, GB 17447, GB/T 17876, GB/T 10004, GB/T 10005, BB/T 0003, BB/T 0025, QB/T 1871, YBB 00162002, YBB 00252005

Configuration
Standard Configuration:Instrument, Test Frame, Micro-printer
Optional Parts:Professional software, Communication cable, Test Accessories (Fixtures for Closed Package Restraining Test, Open Package Unrestrained Test, Fixture for Plastic Pilfer-proof Closure Test, Flexible Tube Test and Aerosol Vale Seal Performance), and Test Device for Blister Pack Seal Performance

Note: 1.The gas supply port of the instrument is Φ8 mm PU Tubing;
          2.
Customers will need to prepare for gas supply.

Leak Tester and Seal Strength Detector for Finished Packages and Three-Side Sealed PackagingLeak Tester and Seal Strength Detector for Finished Packages and Three-Side Sealed PackagingFAQ

Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.

Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.

How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.

Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.

How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.

How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
